REOVIB MFS 268
Operating Instructions EtherNet/IP - Programming
10
6.0 Parameter Table
Non listed addresses cannot be altered!
Parameter: Adjustment Display-
Code
Factory
Setting:
Entry
code
Parameter
address
HEX (.bit)
Value
HEX
Vibratory feeder
• Amplitude (throughput)
0...100 % A. 0 % 000,
002,
008, 096
100C
0x0000...0xFFFF
• Second set point / coarse - fine
0…100 % 2. 0 002 0x1006
0x0000...0xFFFF
• Maximum control limit (U
max
)
5...100 % P. 90 % 096, 008
1009
0CCC...FFFF H
• Vibrating frequency
5...300 Hz F. 100 Hz 096, 008
040
1005
01F4...7530 H
500...30000 dec.
(FL.)...(FH.)
• Soft start ramp up
0...60 sec. /. 0,1 sec. 096 1013
0x0000...0xFFFF
• Soft stop ramp down
0...60 sec. \. 0,1 sec. 096 1012
0x0000...0xFFFF
• Switch to external set point
0 / I E.S.P. 0 003 0x5800
0x0000 / 0x FFFF
• Set point 0(4)...20 mA
0 / I 4.20 0 003 0x5801
0x0000 / 0x FFFF
• Potentiometer set point
(for 3 / 6 / 8 A units)
0 / I POT. 0 003 0x5805
0x0000 / 0x FFFF
• Coarse / Fine control
0 / I S.P.2. 0 003 0x580C
0x0000 / 0x FFFF
• Switch to second set point (delayed)
0 / I S.2.d 0 003
0x0000 / 0x FFFF
• Invert enable
0 / I -En. 0 003 0x5811
0x0000 / 0x FFFF
• Switch status/ ready relay
0 / I r.b. 0 003 0x583D
0x0000 / 0x FFFF
Regulation (with sensor)
• Switch to regulation
0 / I ACC. 0 008 0x5808
0x0000 / 0x FFFF
• P characteristic
0...100 P.A. 40 008 0x100F
0x0000...0xFFFF
• I characteristic
0...100 I.A. 100 008 0x1014
0x0000...0xFFFF
• Automatic frequency control
0 / I A.F.C. 0 008 0x5809
0x0000 / 0x FFFF
• Start automatic frequency search
start A.F.S. 008 0x1400
0x0AF5
Track control
• Switch on time delay
0...60 sec. I. 1 sec. 007, 167
0x1003
0x0000...0xFFFF
• Switch off time delay
0...60 sec. O. 1 sec. 007, 167
0x1002
0x0000...0xFFFF
• Invert sensor
PNP / PNP
inverse
-SE. 0 007, 167
0x580A
0x0000 / 0x FFFF
Sensor control
• Sensor Time-out
0 / I E.En 0 015, 167
0x580B
0x0000 / 0x FFFF
• Sense time delay (Sensor Time-out)
30...240
sec.
E. 180 sec. 015, 167
0x1004
0x0000...0xFFFF
• lead time valve output
1)
0…60 sec. A.r. 0,0 015
0x0000...0xFFFF
• follow-up time valve output
1)
0…60 sec. Ai. 4,0 015 0x102C
0x0000...0xFFFF
Interface (option)
• Interface OFF / ON
0 / I cAn. I 017 0x5818
0x0000 / 0x FFFF
Service
• ERROR Reset
Reset CLr.Er. 009 1400
C009 H
• Hide programming menus
0 / I Hd.C. 117 0x5804
0x0000 / 0x FFFF
• Choose user parameter menu
Nr. 0...3
0...3 U.S.I. 0 143
• Save user settings
PUSH. 143
• Recall factory settings
FAC. 210
• Choose user parameter menu
Nr. 0...3
0...3 U.S.I. 0 210
• Recall user parameter
US.PA. 210
