ATF System with C410:V4B Controller User Guide
33
The Advanced Set-Up screen will display parameters in the following tables:
Field
Description
Max P-FLOW (LPM)
Maximum limit for Pressure FLOW set point (LPM)
Max P-FLOW (sec.)
Maximum limit for Pressure FLOW set point (Seconds)
Min P-FLOW (LPM)
Minimum limit for Pressure FLOW set point (LPM)
Min P-FLOW (sec.)
Minimum limit for Pressure FLOW set point (Seconds)
Max E-FLOW (LPM)
Maximum limit for Exhaust FLOW set point (LPM)
Max E-FLOW (sec.)
Maximum limit for Exhaust FLOW set point (Seconds)
Min E-FLOW (LPM)
Minimum limit for Exhaust FLOW set point (LPM)
Min E-FLOW (sec.)
Minimum limit for Exhaust FLOW set point (Seconds)
PV1 Max (%)
Maximum operating limit for PV1 (%)
PV1 Min (%)
Minimum operating limit for PV1 (%)
PV2 Max (%)
Maximum operating limit for PV2 (%)
PV2 Min (%)
Minimum operating limit for PV2 (%)
PRV1 Max (psi)
Maximum operating limit for PRV1 (psi)
PRV1 Min (psi)
Minimum operating limit for PRV1 (psi)
PRV2 Max (psi)
Maximum operating limit for PRV2 (psi)
PRV2 Min (psi)
Minimum operating limit for PRV2 (psi)
Button
Description
Basic Set Up
Press to switch to Basic Set Up Screen
Help Guide
Press to switch to Start Up Guide Screen
Calibration
Instrument Calibration
Accept / Discard
Change
Accept Change and Discard Change to accept or reject any
parameter change on the screen.
All Primary
All Primary Screen Buttons are displayed to navigate to those
screens
