REPLIGEN XCell ATF10

XCell
TM
ATF System with C410:V4B Controller User Guide
83
Input Page 3
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
0
InputPageX
P2_Cal_Enable
%DB31.DBX376.0
P2 Cal Select Button
Byte
1
InputPageX
PRV1_Cal_Enable
%DB31.DBX376.1
PRV1 Cal Select Button
2
InputPageX
PRV2_Cal_Enable
%DB31.DBX376.2
PRV2 Cal Select Button
3
InputPageX
P3_Cal_Enable
%DB31.DBX376.3
P3 Cal Select Button
4
InputPageX
P4_Cal_Enable
%DB31.DBX376.4
P4 Cal Select Button
5
6
7
1
InputPageX
RequestedDataPage
%DB31.DBW378
Requested Data Page
Int-16
2
3
InputPageX
SendingDataPage
%DB31.DBW380
Sending Data Page
Int-16
4
5
InputPage3
PV1_SP
%DB31.DBD382
PV1 Setpoint Value
%
Real
6
7
8
9
InputPage3
PV2_SP
%DB31.DBD386
PV2 Setpoint Value
%
Real
10
11
12
13
InputPage3
PRV1_SP
%DB31.DBD390
PRV1 Setpoint Value
PSI/Bar
Real
14
15
16
17
InputPage3
PRV2_SP
%DB31.DBD394
PRV2 Setpoint Value
PSI/Bar
Real
18
19
20
21
InputPage3
P2_P1_EU
%DB31.DBD398
P2 First Point Cal Engineering Units
PSI/Bar
Real
22
23
24
25
InputPage3
P2_P2_EU
%DB31.DBD402
P2 Second Point Cal Engineering Units
PSI/Bar
Real
26
27
28
29
InputPage3
PRV1_P1_EU
%DB31.DBD406
PRV1 First Point Cal Engineering Units
PSI/Bar
Real
30
31
32
33
InputPage3
PRV1_P2_EU
%DB31.DBD410
PRV1 Second Point Cal Engineering Units
PSI/Bar
Real
34
35
36
37
InputPage3
PRV2_P1_EU
%DB31.DBD414
PRV2 First Point Cal Engineering Units
PSI/Bar
Real
38
39
40
41
InputPage3
PRV2_P2_EU
%DB31.DBD418
PRV2 Second Point Cal Engineering Units
PSI/Bar
Real
42
43
44
45
InputPage3
P3_P1_EU
%DB31.DBD422
P3 First Point Cal Engineering Units
PSI/Bar
Real
46
47
48
49
InputPage3
P3_P2_EU
%DB31.DBD426
P3 Second Point Cal Engineering Units
PSI/Bar
Real
50
51
52
53
0
InputPage3
P2_P1_Capture
%DB31.DBD430.0
1
P2_P2_Capture
%DB31.DBD430.1
2
P2_Accept
%DB31.DBD430.2
3
PRV1_P1_Capture
%DB31.DBD430.3
4
PRV1_P2_Capture
%DB31.DBD430.4
5
PRV1_Accept
%DB31.DBD430.5
6
PRV2_P1_Capture
%DB31.DBD430.6
7
PRV2_P2_Capture
%DB31.DBD430.7
54
0
InputPage3
PRV2_Accept
%DB31.DBD431.0
1
P3_P1_Capture
%DB31.DBD431.1
2
P3_P2_Capture
%DB31.DBD431.2
3
P3_Accept
%DB31.DBD431.3
