Input Page 4
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
0
InputPageX
P2_Cal_Enable
%DB31.DBX432.0
P2 Cal Select Button
Byte
1
InputPageX
PRV1_Cal_Enable
%DB31.DBX432.1
PRV1 Cal Select Button
2
InputPageX
PRV2_Cal_Enable
%DB31.DBX432.2
PRV2 Cal Select Button
3
InputPageX
P3_Cal_Enable
%DB31.DBX432.3
P3 Cal Select Button
4
InputPageX
P4_Cal_Enable
%DB31.DBX432.4
P4 Cal Select Button
5
6
7
1
InputPageX
RequestedDataPage
%DB31.DBW434
Requested Data Page
Int-16
2
3
InputPageX
SendingDataPage
%DB31.DBW436
Sending Data Page
Int-16
4
5
InputPage4
PV1_SP
%DB31.DBD438
PV1 Setpoint Value
%
Real
6
7
8
9
InputPage4
PV2_SP
%DB31.DBD442
PV2 Setpoint Value
%
Real
10
11
12
13
InputPage4
PRV1_SP
%DB31.DBD446
PRV1 Setpoint Value
PSI/Bar
Real
14
15
16
17
InputPage4
PRV2_SP
%DB31.DBD450
PRV2 Setpoint Value
PSI/Bar
Real
18
19
20
21
InputPage4
P4_P1_EU
%DB31.DBD454
P4 First Point Cal Engineering Units
PSI/Bar
Real
22
23
24
25
InputPage4
P4_P2_EU
%DB31.DBD458
P4 Second Point Cal Engineering Units
PSI/Bar
Real
26
27
28
29
InputPage4
P5_P1_EU
%DB31.DBD462
P5 First Point Cal Engineering Units
PSI/Bar
Real
30
31
32
33
InputPage4
P5_P2_EU
%DB31.DBD466
P5 Second Point Cal Engineering Units
PSI/Bar
Real
34
35
36
37
InputPage4
W1_P1_EU
%DB31.DBD470
W1 First Point Cal Engineering Units
PSI/Bar
Real
38
39
40
41
InputPage4
W1_P2_EU
%DB31.DBD474
W1 Second Point Cal Engineering Units
KG
Real
42
43
44
45
0
InputPage4
P4_P1_Capture
%DB31.DBD478.0
Byte
1
InputPage4
P4_P2_Capture
%DB31.DBD478.1
2
InputPage4
P4_Accept
%DB31.DBD478.2
3
InputPage4
P5_P1_Capture
%DB31.DBD478.3
4
InputPage4
P5_P2_Capture
%DB31.DBD478.4
5
InputPage4
P5_Accept
%DB31.DBD478.5
6
InputPage4
W1_P1_Capture
%DB31.DBD478.6
7
InputPage4
W1_P2_Capture
%DB31.DBD478.7
46
0
InputPage4
W1_Accept
%DB31.DBD479.0
Byte
1
InputPage4
Force_Solenoid
%DB31.DBD479.1
2
%DB31.DBD479.2
3
%DB31.DBD479.3
4
%DB31.DBD479.4
5
%DB31.DBD479.5
6
%DB31.DBD479.6
7
%DB31.DBD479.7
47
48
49
