Note:
Detailed mounting and operating instruc-
tions are available for the The specialised
craftsman.
CE-Declaration of conformity
The product complies with the relevant directives and
is therefore labelled with the CE mark. The Declara-
tion of Conformity is available upon request, please
contact RESOL.
WARNING!
Electric shock!
Damage to the device!
The device contains sensitive live
parts!
Î Do not open the houesing!
Only qualified personnel
may carry out work at the
device!
Disposal
• Dispose of the packaging in an environmentally
sound manner.
• Dispose of old appliances in an environmentally
sound manner. Upon request we will take back
your old appliances bought from us and guarantee
an environmentally sound disposal of the devices.
Description of symbols
WARNING!
Warnings are indicated with a warn-
ing triangle!
Î They contain information
on how to avoid the danger
described.
Signal words describe the danger that may occur,
when it is not avoided.
• WARNING means that injury, possibly life-threat-
ening injury, can occur.
• ATTENTION means that damage to the
appliance can occur.
Î Arrows indicate instruction steps that should be
carried out.
Safety advice
Please pay attention to the following safety advice
in order to avoid danger and damage to people and
property.
Target group
This manual is addressed to the end user of the in-
stallation.
Information about the product
Proper usage
The solar controller is designed for use in standard
solar thermal systems with electric afterheating (im-
mersion heater) in compliance with the technical data
specified in this manual.
Improper use excludes all liability claims.
Note:
Only qualified electricians should carry out
electrical work.
Initial commissioning and parameterisation
must be carried out by a specialised crafts-
man.
Note:
Notes are indicated with an information
symbol.
Contents
1 Product description ................................. 11
1.1 Data communication / Bus ...................................11
2 Technical data: ......................................... 11
3 Operation ................................................. 12
3.1 Buttons .....................................................................12
3.2 Scrolling through the menu ..................................12
3.3 System-Monitoring-Display ..................................12
3.4 Slide switch ..............................................................13
3.5 Flashing codes .........................................................13
4 Adjust date and time .............................. 14
5 Display values ........................................... 14
5.1 Display channels ......................................................14
6 Fault indication ........................................ 15
7 Accessories ............................................. 15
