4. Control parameters and display channels
4.1 Overview of channels
Legend:
x
Corresponding channel is available.
x*
Corresponding channel is available when the corresponding
option is enabled
Only if the option heat quantity measurement is activated
(OHQM), will the corresponding channel be available.
MEDT
Only if an antifreeze (MEDT) other than water or Tyfo-
cor LS / G-LS (MEDT 0 or 3) is used, will the channel
antifreeze concentration (MED%) be displayed.
Only if the option heat quantity measurement is deactivated
(OHQM), will the corresponding channel be available.
Note:
Only if temperature sensors are connected, will S3 and S4
be displayed.
channel
ARR description page
1 2*
COL x x temperature collector 1 11
TST x temperature store 1 11
TSTL x temperature store 1 base 11
TSTU x temperature store 1 top 11
S3 x temperature sensor 3 11
TRF
temperature return sensor 11
S4
temperature sensor 4 11
n % x speed relay 1 11
n1 % x speed relay 1 11
h P x operating hours relay 1 11
h P1 x operating hours relay 1 11
h P2 x operating hours relay 2 11
kWh
heat quantity kWh 12
MWh
heat quantity MWh 12
time clock time 11
ANL 1-2 arrangement
DT O x x switch-on temperature difference 12
DT F x x switch-off temperature difference 12
DT S x x set temperature difference 13
RIS x x rise 13
S MX x x maximum temperature store 1 13
EM x x emergency temperature collector 1 13
channel
ARR description page
1 2
OCX x x option collector cooling
collector 1
13
CMX x* x* maximum temperature collector 1 13
OCN x x option minimum limitation
collector 1
14
CMN x* x* minimum temperature collector 1 14
OKF x x option frost protection collector 1 14
CFR x* x* frost protection temperature
collector 1
14
OREC x x option recooling 14
O TC x x option tube collector 14
AH O x switch-on temperature
thermostat 1
15
AH F x switch-off temperature
thermostat 1
15
t1O x switch-on time 1 thermostat 15
t1F x switch-off time 1 thermostat 15
t2O x switch-on time 2 thermostat 15
t2F x switch-off time 2 thermostat 15
t2O x switch-on time 3 thermostat 15
t3F x switch-off time 3 thermostat 15
OHQM x option heat quantity measurement 12
FMAX
maximum flow rate 12
MEDT
antifreeze type 12
MED% MEDT MEDT antifreeze concentration 12
nMN x minimum speed relay 1 15
n1MN x minimum speed relay 1 15
HND x manual operation relay 1 15
HND1 x manual operation relay 1 15
HND2 x manual operation relay 2 15
LANG x x language 16
PROG XX.XX program number
VERS X.XX version number
