D e lt a S o l
®
C/4
© RESOL 11103 deltasol_c/4.monen.indd
| 8
sensor
collector 1
pumps
sensor
additional symbol
operation of the
burner
valve
store
store heat exchanger
afterheating (with additional
symbol)
store top sensor
collector with collector sensor
pump
store
with heat exchanger
afterheating
with burner symbol
temperature sensor
2.3 Flashing codes
• Pump symbols are flashing during the initialisation phase
• Sensor symbols are flashing when the corresponding sen-
sor display channel is selected.
• Sensor symbols are flashing in the case of a sensor fault.
• Burner symbol is flashing when the after-heating is active.
