BALAN 1
PUSH
hR 1 (... 4)
Operat. hours
Relay 1 … 4
DAYS
Operating days
MAXS1 (... 6)
Max. temp.
Sensor 1 … 6
MINS1 (... 6)
Min. temp.
Sensor 1 … 6
2
1
Operating hours counter
R (1, 2, 3, 4)
Operating hours counter
The operating hours counter accumulates the solar operating hours of the relay
(h R1 / h R2 / h R3 / h R4). Full hours are displayed.
The accumulated operating hours can be set back to zero (see page 38).
Operating days
DAYS
Display of operating days since commissioning or last reset. The operating days
cannot be set back to zero.
Minimum and maximum temperatures
MAXS1(2, 3, 4, 5, 6)
Maximum temperatures at S1 … S6
MINS1(2, 3, 4, 5, 6)
Minimum temperatures at S1 … S6
Indication of the minimum and maximum temperatures at S1 … S6.
The temperature indication can be set back to zero (see page 38).
1
Balance values
