INSTALLATION GUIDELINES

Front Installation for Convertible or Coupe

If your car is a convertible or coupe, it won’t have a B pillar. Instead

you’ll install the anchor point directly to the frame of the car below

the rear window panel (See Figure 7). The retrotting steps in this

section should only be performed by a professional installer.

Remove the interior paneling, and check the desired anchor point

location for structural integrity and signs of rust. Hold the anchor

mount in place and trace with a felt-tipped marker to make a

template. Then drill your hole and install the anchor mount by

holding the mount into place and placing the bolt through the hole.

You can also reinforce the anchor mount by riveting or welding the

mount into place (See page 8 for welding instructions). Tighten the

bolt down and reinstall interior panels. Then install the belt end

(See Figure 7).

Figure 7

Cutaway of behind and

below window panel

showing placement of

anchor mount

Belt end mounts to oor

using round anchor mount

installed beneath the oor

pan or to the frame.

Placement of anchor mount

for front shoulder harness
