Retsch RM200 - Operating Elements and Functions

11/6/2012 13  Retsch GmbH 0002
Operating elements and their function
General plan
Element
Description
Function
A
Machine socket
Connection for power cable of machine
B
Fuse compartment
Takes two visible type fuses
C
Type plate
Information on the machine and connected
loads
D
ON/OFF switch
For switching the RM200 on and off
E
Display and operating unit: For
explanations see below
Time preselection and starting / stopping the
machine
F
Closing grip
For opening and locking the millling chamber
G
Turning handle – pestle pressure
adjustment
Turning alters the pestle contact pressure
H
Scale
Setting guide for pestle pressure
I
Filling opening
Sample material is filled here
J
Viewing window
Viewing possibility during the milling
process, particularly for adjusting the
scraper
K
Setting knob for scraper
Sets the contact pressure or gap of scraper
L
Pestle setting knob
For adjusting the pestle on the mortar wall
M
Hood
Closes the milling chamber
