System light blinks
when checking for
or performing an
update. (DO
NOT POWER OFF).
Your IQMC router provides fast dual-band Wi-Fi for all your devices, and
features built-in network security, guest Wi-Fi, and automatic software
updates OTA (over-the-air).
Reset Button
If you experience difficulties with your router, please check the antenna connections, as well as making sure power is connected. You
may also want to move the router to another location as this may affect it's functionality. If it is still not connecting, you
can do a hard reset. Press the reset button for 2-3 seconds, and then allow the router to cycle for 5 minutes before
attempting to connect.
When 5G light
is on, then short
range Wi-Fi is
available.
If 2.4G light is
on you have
long range Wi-Fi
availability
If power light
is on, you have
power to the unit
USB is
for future use.
LAN ports are used to
directly connect other
devices to the internet
via ethernet cable.
WAN port is used to
connect a primary
internet source for
failover.
Hard reset button:
DO NOT PRESS.
DC port: the DC /
power adapter is
connected and then
plugged into the
wall for power.
SIM removal:
DO NOT USE.
SIM: do not
remove.
When 5G light is on, short
range Wi-Fi is available
4G/5G light is
on when you are
connected to the
network. Flickering
light means data is
being transmitted.
