REWIRE SECURITY 104 PRO - Installation; Installation Process

5
5. Specifications
Content
specifications
DIM.
94mm*60mm*38mm
Weight
300g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS sensitivity
-159dBm
GPS Accuracy
5m
GPS Start time
Cold status
45s
Hot status
1s
EXT. power
DC 12 V -24V
Operating Current
Sleep Current
1.8mA
Deep sleep
0.6mA
GSM operating Current
68mA±3mA
GPRS Current(data transfer)
82mA±10mA
Battery
3.7V 6000mA/h Polymer battery
Charge current
1A±0.2A
Charge time
7h
Standby time
Sleep
1-2 months
Deep sleep
4-8 months
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +65°C
Humidity
5%--95% non-condensing
II. Installation
1. Installation
1.1 104-PRO can be either attached to a flat metal surface or mounted using the
fixing brackets.
1.2 External GPS & GSM antennas are provided inside the box. These can be
used to increase signal strength if required.
