ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
MODEL CB405E
Power Supply 230V 50Hz
115V 60Hz – US Variant – See Issue 16
Motor Power 140W
Height 190 mm (7.48 ins)
Width 480 mm (18.90 ins)
Length 430 mm (16.93 ins)
Weight 15 kg (33 lbs)
Entry Width 310 mm (12.20 ins)
Hole Pitch 14.2 mm (9/16 ins - US Pitch)
Punch Capacity (Sheets) 30 Sheets of 80 gsm
30 Sheets of 20 lb bond – See Issue 16
Comb Size Upto 50mm
Wire Size Upto 14mm
No of Punches 21 (3 selectable)
Edge Margin Adjustment Yes
Back Margin Adjustment Yes
Handle Locking Yes
Max Document Size (Comb Bound) 450 sheets
Max Document Size (Wire Bound) 100 sheets
