ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
MODEL WB705E
Power Supply 230V 50Hz
Motor Power 140W
Height 190 mm (7.48 ins)
Width 440 mm (17.32 ins)
Length 430 mm (16.93 ins)
Weight 12.5 kg (27.5 lbs)
Entry Width 310 mm (12.20 ins)
Hole Pitch 8.46 mm (1/3 ins - International Pitch)
Punch Capacity (Sheets) 25 Sheets of 80 gsm
Comb Size N/A
Wire Size 5mm to 14mm
No of Punches 34 (2 selectable)
Edge Margin Adjustment Yes
Back Margin Adjustment No
Handle Locking Yes
Max Document Size (Comb Bound) N/A
Max Document Size (Wire Bound) 140 sheets
