ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
AMENDMENT RECORD SHEET
ISSUE
NO
DECRIPTION SERIAL
NO
CARO
NO
1 Original 301
2 Page 15 – Model WB705E – Part No D55237,
WB705E LED PCB Cover added
A665070 538
3 Part No D55236 – Gear Box Shaft Retainer added to
all Models. Omitted in error on original compilation.
--
4 Part No D55242 – Thermal Fuse Assembly added to
all Models. Additional safety feature should the
automatic thermal cut out in the Motor fail.
A670764 558
5 Part Nos D55241 – Compound Gear 41/10T (Metal) &
PLN29 – M5 Plain Washer to replace D55190 on all
Models to prevent failure under extreme abuse.
A678191 549
Issue 2
6 Part Nos SL18-361 – Cable Clamp and SCR718 – M4
x 10 Plasform screw added all Models to secure
Ribbon Cable between Main and Switch PCB’s
A677022 564
7 Part No SL18-377 – Insulating Tape added to all
Models to give extra protection to the Ribbon Cable
between Main and Switch PCB’s
A677022 571
8 Part No SL18-377 x 100mm changed to SL18-380 x
75mm length. Part No Duplicated.
A677022 587
9 Part No D000430 – Wire Adjuster Indicator Decal no
longer required. Scale pad printed directly onto Fixed
Jaw itself (part No D55083B).
A692162 577
10 Wire closing mechanism on WB705E improved. A692162 585
11 The additional Thermal Fuse Assy (See Issue 4 above)
is no longer required as the automatic thermal cut out
in the Motor has been uprated.
A694090 558
12 Part No D55240 – Compound Gear 41/10T (Sintered)
replaces D55241 and PLN29 (See Issue 5 above)
A710069 548
13 Australian variants to Model CB355E, CB405E and
WB705E added. Specification for all models added
(Pages 42 – 45)
A715715 603
14 On/Off switch added to all Models resulting in new
Main (SL17-314) and LED (SL17-313) PCB’s and
additional Part No SL18-383 – Printed Button, with
Part Nos D55247 – Ribbon Cable Bridge Piece and
SCM160 – M4 x 12 Pan Torx Taptite Screw (1 off)
added to CB405E and WB705E only
A717393
CB355E
A721022
CB405E
A721641
CB345E
598
