The rearview camera has two wire routing options as shown in the above figure. For
both options, it is suggested that you conceal the wiring against the edges of the
car's door.
Rearview Camera Wiring Instruction (as shown below)
2.
Align the male portion
and the female portion
of the rearview camera
cable between the
arrows before pressing
the connectors together.
Connected to rearview camera
Connected to reverse light
A
B
10
