5. Move the red line up or down to the horizon (the intersection line between sky
and Earth). Move the yellow line up or down to the interface between the car’s tail
and ground. Move the green line left or right to the focal point where the far end
road intersects with the horizon. After proper adjustment, click Next to access
calibration of the warning range.
4. Click to access the RCW calibration interface. You will initially see the
concept and a brief introduction on the calibration page. Click Next to access the
real calibration interface, as shown below:
21
RCW CALIBRATE
The yellow box is the alarm area to
prevent rear-end collision and
reversing areas (close distance).
Button to adjust the red dot and
alarm area.
NEXT
