42
NOTE: The Scan Type setting will determine whether computers must be eye-marked to be included
in the scan. See page 27 for details.
Manual Scan
Manual Scan enables you to manually switch back and forth between powered computers:
left Ctrl + left Ctrl + F2 1
Press the up or down arrow to select the previous or next computer in sequence. Press any other key
to abort the Manual Scan.
NOTE: The Scan Type setting will determine whether computers must be eye-marked to be included
in the scan. See page 27 for details.
Scan Rate
Scan Rate sets the duration between switching to the next computer in Auto Scan mode:
left Ctrl + left Ctrl + F3 1
The unit switches between scan intervals of 3, 8, 15 and 30 seconds.
Keyboard Typematic Rate
You can adjust the keyboard typematic rate (given in characters/sec). This setting over-rides the
keyboard typematic rate of your BIOS and any operating system.
left Ctrl + left Ctrl + F4 1
The unit switches between rates of 10, 15, 20 and 30 characters/sec.
Audio Stick
A multimedia module can be LINKed to the back of the Master switch
for selecting microphone and
stereo speaker signals. There are two options for Audio Stick: On and Off. When set to On, audio
selection follows computer selection. When set to Off, audio selection stops following computer
selection. It is useful if you want to listen to a particular computer's audio signal while operating other
computers.
left Ctrl + left Ctrl + F5 1
(NOTE: This is an optional feature requiring a separate device to be connected to the Master switch
.)
Changing Your Configuration
After the initial power up, any device (either a KVM or a PC) can be added or removed from any PC x
port on the KVM without having to power down the Master switch
. Make sure that devices are turned
offer before connecting them to the Master switch
.
NOTE: After changing your configuration, the KVM-OSD will automatically update to reflect the new
configuration.
