Appendix B Specifications
Maximum supported video mode 1600x1200 @ 85Hz
Standard video modes supported 640x400 @ 85Hz
720x400 @ 85Hz
640x480 @ 60Hz
640x480 @ 72Hz
640x480 @ 75Hz
640x480 @ 85Hz
800x600 @ 56Hz
800x600 @ 60Hz
800x600 @ 72Hz
800x600 @ 75Hz
800x600 @ 85Hz
1024x768 @ 60Hz
1024x768 @ 70Hz
1024x768 @ 75Hz
1024x768 @ 85Hz
1152x864 @ 75Hz
1280x960 @ 60Hz
1280x960 @ 85Hz
1280x1024 @ 60Hz
1280x1024 @ 75Hz
1280x1024 @ 85Hz
1600x1200 @ 60Hz
1600x1200 @ 65Hz
1600x1200 @ 70Hz
1600x1200 @ 75Hz
1600x1200 @ 85Hz
Color Depth
8 BITS / 12 BITS / 16 BITS Selectable
Maximum power consumption 18 watts
Input Connectors Video In (for local console)
PS/2 Keyboard (for local console)
PS/2 Mouse (for local console)
USB Keyboard (for UCIP-01/ 04 / 08 / 16 local console Only)
USB Mouse (for UCIP-01/ 04 / 08 / 16 local console Only)
LAN RJ-45
Serial Supervisor (RJ-14)
DB9 RS-232 Male (DTE)
DC in
UCIP/UNIP/MNIP-01 : 1 x HDB15 (female) Integrated KVM Cable
Input
UCIP/UNIP/MNIP-04: 4 x HDB15 (female) Integrated KVM Cable
Input
UCIP/UNIP/MNIP-08: 8 x HDB15 (female) Integrated KVM Cable
Input
UCIP/UNIP/MNIP-16: 16 x HDB15 (female) Integrated KVM Cable
Input
WMM/WUM-001: 1 x HDB15 (female) Integrated KVM Cable Input
WMM/WUM-108D: 8 x HDB15 (female) Integrated KVM Cable
Input
WMM/WUM-116D: 16 x HDB15 (female) Integrated KVM Cable
Input
Dimensions W x H x D (mm) UCIP/ UNIP/MNIP-01: 186 x 43 x 220
UCIP/UNIP/MNIP-04: 186 x 43 x 220
UCIP/UNIP/MNIP-08: 404 x 43 x 220
UCIP/UNIP/MNIP-16: 404 x 43 x 220
WMM/WUM-001: 404 x 43 x 220
WMM/WUM-108D: 404 x 43 x 220
WMM/WUM-116D: 404 x 43 x 220
