Country Code for Sun (For UCIP-04 / 08 / 16, UNIP-04 / 08 / 16, WUM-108D / 116D only)
Sun keyboards of different languages have different layouts. The KVM switch is able to emulate
a Sun keyboard for a specific language type or country such as Arabic, Belgian, US,
Yugoslavia, and so forth. Select the proper country code that matches ALL of your Sun
computers.
Max. Resolution (For UCIP-04 / 08 / 16, UNIP-04 / 08 / 16, WUM-108D / 116D only)
You can adjust the monitor resolution under this sub-menu. There are the following selections:
1024*768, 1280*1024, 1600*1200, 1920*1440, and “DDC2B Disable”.
Function key F5 : (For UCIP-04 / 08 / 16, UNIP-04 / 08 / 16, WUM-108D / 116D only) To
switch the Sun mark of a port on or off indicating the computer is a Sun server. Sun servers have
more keys on the keyboard than a PC. When a Sun-marked port is selected, the KVM Switch
starts to translate the keys from a PS/2 keyboard to a Sun keyboard. See Sun Keyboard Mapping
for detail.
Esc : To exit the KVM-OSD, press the Esc key.
C. Hot Key Commands
A hot key command is a short keyboard sequence to select a computer, activate a computer scan, etc.
A hot-key sequence starts with two Left Control keystrokes followed by one or two more keystrokes.
The short form hot-key menu can be turned on as an KVM-OSD function ( F4 : More\Hotkey Menu)
every time the left Ctrl key is pressed twice.
Left Ctrl refers to the Ctrl key located at the left side of the keyboard.
1~8/A~H refer to the number keys 1 to 8 at the upper row of the keyboard (Do not use the keypad at
the right of the keyboard) and character keys A to H (case insensitive).
Selecting a Computer
To select a computer by hot-key command you need to know the device’s channel address, which is
determined by the KVM connection. For a computer connected to the Master switch
, the address is
represented by the PC port number (1~8/A~H). For example, to access the PC plugged into port 7 of
the Master switch
, type:
left Ctrl + left Ctrl + 7 1
For a computer connected to a Slave KVM, you need to know the channel address of the Slave unit
(1~8) and then the channel address of the device (1~8/A~H). (Please note that only Master's PC 1~8
ports can be connected to a Slave.) For example, to access the computer plugged into console port
of a Slave KVM
that is plugged into Port 6 of the Master switch, type:
left Ctrl + left Ctrl + 6 + C 1
Auto Scan
Auto Scan automatically scans through powered computers at a fixed interval:
left Ctrl + left Ctrl + F1 1
When Auto Scan detects any keyboard or mouse activity, it suspends the scanning until activity stops;
it then resumes with the next computer in sequence. The length of the Auto Scan interval (Scan Rate)
is adjustable (see Scan Rate on the following page). To abort the Auto Scan mode, press the left Ctrl
key twice.
