MicroLite Receiver User Manual
Revision 1.1 10
Table 2-1: MICROLITE RECEIVER - Summary of Features and Benefits
Feature
Benefit
COFDM HD and SD
Microwave Receiver
COFDM facilitates high data rates and robust signal reception.
Receives both high definition and standard definition video
transmissions.
Dual Antenna Diversity Using
Maximal-Ratio Combining
Best aspects of the transport stream received using either antenna is
used, yielding robust, error free reception.
MPEG4 (H.264 part 10)
Video Decoder
Industry standard video decoding.
Integrated with IMT maximal-ratio combining scheme.
ASI, HD-SDI or SD-SDI, and
Composite Video Outputs
Compatible with industry standard A/V equipment.
SDI format switches automatically between HD and SD.
User Data Channel
An RS-232 data channel is received along with the program streams.
Stereo Audio Line Outputs
Line audio outputs for connection to headphones, an amplifier, or
recorder. Audio is also available in ASI and SDI outputs.
Remote Control
Via RS-232 Serial Interface
The MLR is pre-programmed for its operating environment using a
built-in web GUI via LAN or optional Remote Control Windows PC
GUI.
Faceplate User Interface with
Presets and Status LED’s
Users can quickly select one of 16 pre-programmed preset
configurations. This is through the programmable serial interface or
by using the optional front panel user interface.
Status and Alarm information is available at a glance.
Rugged, Compact Housing
Integrated in small form factor.
