MicroLite Receiver User Manual
Revision 1.1 11
2.2 Frequency Bands
The microLite Receiver is available in the following bands:
Table 2-2: MLR Frequency Bands
2.3 microLite Receiver Theory of Operation
Major blocks in the MLR diagram include:
Dual Antenna Inputs
Dual Microwave Receiver and COFDM Demodulator Circuits
Dual Input Maximal Ratio Combining Circuit
MPEG4 Video Decoding Circuit
Video Output Interfaces: ASI, SDI, and Composite Video
Left and Right Audio Output Interfaces
Preset Selection and Status Monitoring User Interface (Optional)
Programmable Serial Interface and Internal Control CPU With Flash Memory
Interface For Firmware Upgrades
Power Circuitry
Refer to Figure 2-1: Internal Block Diagram for following discussion.
