MicroLite Receiver User Manual
Revision 1.1 17
3.5 System
ASI Output: Auto output rate follows modulation
or fixed output user selectable
(PCR Retime stamp)
User Data: RS232 Side channel; 300-115K Baud
Latency (*using MicroLite Transmitter):
o 4 frames in Low Latency Mode for all
formats except PSF
o 5 frame in Low Latency Mode for PSF
formats
Ethernet: 100 Mbps Ethernet interface.
Streaming Video: Streaming MPEG-TS over UDP/RTSP
Remote Control: Via LAN and/or PC GUI
3.6 Power Requirements
Input range: DC: +9 to +32
Power consumption: 9W Typical
3.7 Environmental
3.7.1 Temperature Range
Full specification: -10° to 50°C Ambient
Storage: -40° to 80°C
Humidity: 0 to 95% non-condensing
3.7.2 Altitude
Operating: 20,000ft (6,000 m)
Storage: 50,000ft (15,000 m)
3.7.3 Physical Characteristics
Size: 3.7" x 5" x 1.5"
Weight: 620g/1.4lbs
3.8 User Interface and Remote Control
One button control (16 user defined presets)
Remote RS232
WEB GUI
