CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
PARTS LIST
MODEL NO. 812N&812G
170 195063
Tension Indication Plate
1
173A 18122
Shaft Assembly
1
176 181210
Sliding Plate
2
177 181211
Blade Tension Sliding Block
1
178 S608
Hex. Socker Headless Screw
5/16"-18*3/4"L 1
179 S019
Hex. Head Screw
5/16"-18*1-1/2"L 2
180 W015
Washer
5/16"x12xt2 2
181 S022
Hex. Head Screw
5/16"-18*3/4"L 4
182 W205
Spring Washer
5/16"-18 4
183 181212
Spring
1
184 W008
Washer
3/8"x25xt2 1
185 181213A
Blade Adjustable Knob
1
186 S405
Cross Round Head Screw
1/4"-20*3/8"L 1
187 195429 Blade Cover 1
190S 195432S Blade Adjustable Assembly 1
190-1 195432 Blade Adjustable 1
190-2 195434 Adjustable Bracket (Front) 1
190-5 HT018
Button Head Screw
M8X25L 2
190-6 HS422
Hex. Socker Headless Screw
M6-1.0P*10L 2
190-7 HS423
Hex. Socker Headless Screw
M6-1.0P*15L 2
190-8 HN012
Hex. Nut
M10-1.0P 2
190-9 HW106
Spring Washer
M10 2
190-10 103120A
Carbide Guide
2
190-11
HT004
Hex. Socket Head Screw
M6*16L
2
190-12 121018N
Guide
1
190-14 HW032
Washer
ø6.3Xø13Xt1.6mm 2
190-15 HW104
Spring Washer
M6 2
191A 121019NAS Eccertric shaft Assembly 2
191-1 121019NA Eccertric shaft 2
191-2 CA608ZZ
Bearing
608ZZ 2
191-3 HCS01
C-Retaniner Ring
S10 2
192A 121019NBS
Bearing Shaft Assembly
2
192-1 121019NB
Bearing Shaft
2
192-2 CA608ZZ
Bearing
608ZZ 2
192-3 HCS01
C-Retaniner Ring
S10 2
193 HS509
Cross Round Head Screw
M4-0.7Px10L 2 812 For CE Only
194 HW003
Washer
M5 2 812 For CE Only
195 195061
Switch Base
1 812 For CE Only
196 195041
Grip
1
197 W008
Washer
3/8"x25xt2 1
198S 195035CS
Brush Assembly
1
