CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
PARTS LIST
MODEL NO. 812N&812G
198-1 195035C
Brush Support
1
198-2 181241C
Brush
1
198-3 HS036
Hex. Head Screw
M6x30L 1
198-4 HW016
Washer
ø6.5Xø18Xt1.5mm 2
198-5 HN004
Hex. Nut
M6 2
200 S405
Cross Round Head Screw
1/4"-20*3/8"L 2
201 W005
Washer
1/4"x16xt1.5mm 2
202S 195432S Blade Adjustable Assembly(Rear) 1
202-1 195433 Blade Adjustable (Rear) 1
202-5 HN012
Hex. Nut
M10-1.0P 2
202-6 HW106
Spring Washer
M10 2
202-13 103120
Carbide Guide
2
202-14
HT004
Hex. Socket Head Screw
M6*16L
2
202-15 121018N
Guide
1
202-16 HW032
Washer
ø6.3Xø13Xt1.6mm 2
202-17 HW104
Spring Washer
M6 2
205 HT018
Button Head Screw
M8X25L 2
211 S022
Hex. Head Screw
5/16"-18x3/4"L 4 812N
212 W016
Washer
5/16"x23xt2 4 812N
213 181233A
Motor Mount Bracket
1 812N
214 W018
Washer
5/16"x23xt3 2 812N
215 S022
Hex. Head Screw
5/16"-18x3/4"L 2 812N
216 S504
Carriage Screw
5/16"-18x3/4"L 4 812N
217 181234A
Motor Mount Plate
1 812N
218 S017
Hex. Head Screw
5/16"-18x1"L 2 812N
219 N007
Hex. Nut
5/16"-18 2 812N
220
Motor
1 812N
221 W016
Washer
5/16"x23xt2 4 812N
222 N007
Hex. Nut
5/16"-18 4 812N
223 S604
Hex. Socker Headless Screw
1/4"-20x3/8"L 1 812N
224 181235
Motor Pulley
1 812N
225 K008
Key
5x5x30L 2 812N
226 S201
Cross Socker Hex. Head Screw
1/4"x1/2"L 2 812N
227 W004
Washer
1/4"x19xt1.5 2 812N
228 181237I
Motor Pulley Cover
1 812N
229 W005
Washer
1/4"x16xt1.5 1 812N
230 S201
Cross Socker Hex. Head Screw
1/4"-20x1/2"L 3 812N For CE Only
230 3058
Plum handle
1 812N
244S 18138
Worm Gear Shaft Assembly
1 812N
244-1 181223
Worm Shaft
1 812N
244-2 K008
Key
5x5x30L 1 812N
812 For JET Only
-24 -
