CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
PARTS LIST
MODEL NO. 812N&812G
244-3 CA6003LLU 2 812N
244-4 181224 1 812N
244-5
HCS06
1 812N
245S 181216AS 1 812N
245-1 181216A 1 812N
245-2 3149 1 812N
245-3 S202 4 812N
245-4 181222-1 1 812N
245-5 3092
Bearing
6003LLU
Bearing Bushing
C-Retaniner Ring
S17
Gear Box Assembly
Gear Box
Vent Plug
M8xP1
Cross Socker Hex. Head Screw
1/4"-20x5/8"L
Gear Box Cover
Gear Box Gasket
1 812N
245-6 HCS13
C-Retaniner Ring
S25 1 812N
245-7 HK025
Key
6x6x20L 1 812N
245-8 181220-1
Worm Gear
1 812N
245-9 181218-1
Bushing
1 812N
245-10 CA6205LLU
Bearing
6205LLU 2 812N
245-11 181217-1
Bushing
1 812N
245-12 181219-1
Transmission Wheel Shaft
1 812N
245-14 181246
Bearing Cover
1 812N
245-15 S708
Cross Round Head Screw
3/16"x3/8"L 3 812N
245-16 S609
Hex. Socker Headless Screw
5/16"x3/8"L 1 812N
246 181237D
Cover
1 812N
254 181226B
Spindle Pulley
1 812N
255 S604
Hex. Socker Headless Screw
1/4"-20x3/8"L 2 812N
266 181874
Belt
3Vx270 1 812N
272 195084
Cable Clamp
2
281 S208
Hex. Head Screw
1/4"X1/2"L 8
282 W005
Washer
1/4"x16xt1.5 16
283 N003
Hex. Nut
1/4"-20 8
284 S010
Hex. Head Screw
3/8"-16*1"L 8
285 W013
Washer
3/8"x20xt2 16
286 N005
Hex. Nut
3/8"-16 9
287S 195071S
Valve Assembly
1
300
Motor
1 812G4
300-1 HK110
Key
5x5x30L 1 812G4
300-2 HS059
Hex. Head Screw
M10x25L 4 812G4
300-3 HW106
Spring Washer
M10 4 812G4
300-4 ET2111 Cable Gland PG13.5 2 812G4
300-5 ET2904 Screw On Wire Connector Y3 4 812G4
310S Box Assemble 1
345 181991
Emergency Switch Bracket
1 812 For CE Only
345 181998A
Control Base
1
345 181969
Control Box Base
1 812N
