RF 812N - Page 28

CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
PARTS LIST
MODEL NO. 812N&812G
345 181970
Control Box Base
1 812G4
348 S727
Cross Round Head Screw
M6x12L 4
351
HS228
Hex. Socket Head Screw
M6-1.0Px10L 2
750S1 ET1615S
Switch Ass
1
750-1 S708
Cross Round Head Screw
3/16"x3/8"L 2
750-2
ET1931
Switch COVER
1
750-3 181431
Rubber Plate
1
750-4 ET1615
Switch
MJ1308R 1
750-5 HN002
Hex. Nut
M4 2
750-6 HW305
Washer
M4 4
750-7 HS513
Cross Round Head Screw
M4-0.7Px30L 2
750-8 ET1201
cover
CB2 1
750-9 HS511
Cross Round Head Screw
M4-0.7Px20L 2
750S2 ET1403S
Toggle Switch Assembly
1
750-1 181932
Toggel Switch Cover
1
750-2 3131B
Switch Cover
1
Toggle Switch Assembly
Switch indicator
Hex. Nut
Toggle Switch Assembly
Switch indicator
Hex. Nut
750-4 S804
Screw
3/16"x3/8"L 2
750-5 ET1931
Cover
1
750-6 181431
Rubber Plate
1
750-7 ET1930
Electrical Box
1
750-8 S807
Screw
5/32"x1/8"L 2
750-9 ET2108
Wire Nipple
5/8" 2
750-10 ET2107
Wire Nipple
1/2" 2
750S3 ET1617S
Switch (For CE Only)
1
750-1 S708
Cross Round Head Screw
3/16"x3/8"L 2
750-2 181989-1
Switch Bracket(For CE Only)
1
750-3 ET1617
Switch (For CE Only)
1
750-4 S708
Cross Round Head Screw
3/16"x3/8"L 2
800S 192321G4SA
Gear Box
G4 1 812G4
800-1 192321G4
Gear Box
1 812G4
800-2 192322G4
Gear Box Cover
1 812G4
800-3 192324
Speed-Changing Gear Shaft
1 812G4
800-4 2450079
Speed Lever
1 812G4
800-5 2450080
Spring
1 812G4
800-6 HB001
Steel Ball
∮8 1 812G4
750-3 1
1750-3
ET1403
ET1406
For 1PH Only
For 3PH Only
-26 -
