15. Lighting4 devices
15.1. Proluxx projection screen
Use Lighting4 with a pulse timing of 360
UP 1110 1101 0101 1001 0101 0010 ED 59 52
STOP 1110 1101 0101 1001 0101 1000 ED 59 58
DOWN 1110 1101 0101 1001 0101 0100 ED 59 54
RESET 1110 1101 0101 1001 0101 0001 ED 59 51
15.2. Kingpin (KP100) projection screen
Use Lighting4 with a pulse timing of 1040
UP 1110 0001 0100 0010 0010 0010 E1 42 22
STOP 1110 0001 0100 0010 0010 0100 E1 42 24
DOWN 1110 0001 0100 0010 0010 1000 E1 42 28
PROGRAM 1110 0001 0100 0010 0010 0001 E1 42 21
15.3. Mercury remote control mains sockets
http://mercury.avsl.com/product?range=ME5124
Use Lighting4 with a pulse timing of 188
1 OFF 01000100010101010011 1100
1 ON 01000100010101010011 0011
2 OFF 01000100010101011100 1100
2 ON 01000100010101011100 0011
3 OFF 01000100010101110000 1100
3 ON 01000100010101110000 0011
4 OFF 01000100010111010000 1100
4 ON 01000100010111010000 0011
5 OFF 01000100011101010000 1100
5 ON 01000100011101010000 0011
15.4. Conrad 034911 sockets
http://www.conrad.nl/ce/nl/product/034911/Draadloze-schakelaarset-5-delig
Use Lighting4 with a pulse timing of 425
Off = last 2 digits: 00
ON = last 2 digits: 01
Group Unit
I 1 OFF 00 01 01 01 00 01 01 01 01 01 01 00
II 1 OFF 01 00 01 01 00 01 01 01 01 01 01 00
III 1 OFF 01 01 00 01 00 01 01 01 01 01 01 00
IV 1 OFF 01 01 01 00 00 01 01 01 01 01 01 00
I 1 OFF 00 01 01 01 00 01 01 01 01 01 01 00
I 2 OFF 00 01 01 01 01 00 01 01 01 01 01 00
I 3 OFF 00 01 01 01 01 01 00 01 01 01 01 00
I 4 OFF 00 01 01 01 01 01 01 00 01 01 01 00
I 1 OFF 00 01 01 01 00 01 01 01 01 01 01 00
I 1 ON 00 01 01 01 00 01 01 01 01 01 01 01
