8.1 Specification
Connectors
Input
HDMI In
4×HDMI-A
Output
HDMI Out
1×HDMI-A
USB 3.0
1×USB TypeA
Audio
In
1×3.5mm Stereo Jack
Out
1×3.5mm Stereo Jack
Communication
LAN
1×RJ45
Power
1×DC Power Jack
Performance
Input
Resolutions
HDMI
SMPTE
VESA
720p@50/60 |1080i@50 | 1080p@23/24/30/50/60
1024×768@60 | 1280
×
720@60 | 1280×768@60 | 1280×800@60 |
1280×1024@60 | 1360×768@60 | 1366×768@60 | 1440×900@60 |
1600×1200@60 | 1680×1050@60 | 1920×1080@60 | 1920×1200@60
Output
Resolutions
HDMI
SMPTE
VESA
USB |H.265
720p@60 | 1080p@60
1024×768@60 | 1280×720@60 | 1280×768@60 |
1280×1024@60 | 1360×768@60 |1920×1080@60
1024×768@60 | 1280×720@60 | 1280×1024@60 | 1360×768@60 |
1920×1080@60
Supported
Standards
HDMI
1.3
USB
3.0
H.265
ITU-T H.265/ ISO/IEC 23008-2
Power
Input Voltage
DC 12V/1.5A
Contact Power
13.2W
Max Power
18W
Environment
Temperature
0
℃
~70
℃
Humidity
10%~85%
Physical
Weight
Net
0.5kg
Package
1.25kg
Dimension
Net
180mm×112.5mm×48.7mm
Package
255mm×145mm×85mm

RGBlink Mini Specifications

General

Video Inputs	4x HDMI
Ethernet	Yes
Video Outputs	1x HDMI
Audio Inputs	HDMI embedded
Audio Outputs	HDMI embedded
Control	USB
Transitions	Cut, Fade, Wipe
Power Supply	12V DC
