mini+ User Manual
47
Chapter 8 Appendix
8.1 Specification
Connectors
Input
HDMI In
4×HDMI-A
Output
HDMI Out
1×HDMI-A
USB 3.0
1×USB TypeA
Audio
In
1×3.5mm Stereo Jack
Out
1×3.5mm Stereo Jack
Communication
LAN
1×RJ45
Power
1×DC Power Jack
Performance
Input
Resolutions
HDMI
SMPTE
VESA
720p@50/60 |1080i@50 | 1080p@23/24/30/50/60
1024×768@60 | 1280
×
720@60 | 1280×768@60 |
1280×800@60 | 1280×1024@60 | 1360×768@60 |
1366×768@60 | 1440×900@60 | 1600×1200@60 |
1680×1050@60 | 1920×1080@60 | 1920×1200@60
Output
Resolutions
HDMI
SMPTE
VESA
USB |H.265
720p@60 | 1080p@60
1024×768@60 | 1280×720@60 | 1280×768@60 |
1280×1024@60 | 1360×768@60 |1920×1080@60
1024×768@60 | 1280×720@60 | 1280×1024@60 |
1360×768@60 | 1920×1080@60
Supported
Standards
HDMI
1.3
USB
3.0
H.265
ITU-T H.265/ ISO/IEC 23008-2
PTZ
VISCA
Power
Input Voltage
DC 12V/1.5A
Contact Power
13.2W
Max Power
18W
Environment
Temperature
0
~70
Humidity
10%~85%
Physical
Weight
Net
0.5kg
Package
1.25kg
Dimension
Net
180mm×112.5mm×48.7mm
Package
255mm×145mm×85mm
