mini+ User Manual
3.3 Switch Source
When you access the four source buttons, the lights on the source buttons will appear in four states:
green constant: the signal is recognized, no action is being taken;
green flashing: the currently selected,signal is being edited;
red constant: the signal is currently on the main output;
unlit: the source is not accessed or the resolution of the accessed source is not supported by the mini+
After transition effect (MIX) and transition mode (MODE) is selected
In FAST+Time Mode:
Note：The IP address of mini + and PTZ should be in the same network segment.
3.Rotate 「 Y 」 knob and turn on
corresponding ENABLE
mini+ can control up to 8 cameras.
Note: When operating the camera, mini+ needs to remain in the Control interface, otherwise the PTZ camera
cannot be controlled.
4.Push MENU and back to <CONTROL> ,then
you can control PTZ camera’s position,zoom
and focus.
2.Selected source will be switched to the output wit
h the set fade TIME and using the MIX
transition selected, with the pressed source button
becoming red.
1.Press a source button (1, 2, 3, or 4)
that is green.
