8 PARTS LISTS
Each item number on the following parts lists can be matched with the item number shown on the corresponding
assembly drawing as indicated below.
Refer to Figure 8-1.
Item Number Part Number Quantity Description
1 0400574 1 TOP SHEAVE BRACKET
2 0400575 4 SPRING,BOLT, & NUT – TOP SHEAVE
3 7300653 1 SNAP SAFETY HOOK
5803519 1 CARRIAGE BOLT
5806370 1 LOCKNUT
4 0401424 1
TOP SHEAVE BRACKET MTG HDWR KIT
consisting of: 4ea carriage bolt & wing nut
5 0420405 CROSS TIE BRACE*
6 0401499 2 PIVOT BRACKET GUIDE ROLLER ASSY
7 0401430 1 PIVOT BRACKET
8 0401214 12 TROLLEY WHEEL KIT*
9 0401410 1 MAIN FRAME
10 7303600 1 SHEAVE
5805910 1 U-BOLT
5806367 2 LOCKNUT
11 7806009 1 BUMPER
12 0420401 2 TRACK SWIVEL SHOE MTG BRKT*
13 0420402 2 TRACK SWIVEL SHOE*
14 0420403 2 CROSS TIE STIFFENER
15 0404804 4 GUIDE ROLLER WHEEL KIT*
16 0404208 2 PLATFORM SUPPORT BRACE
5806280 4 HEX HEAD CAP SCREW
5806379 4 HEX NUT
17 0401420 1 PLATFORM FRAME
18 0404218 2 PLATFORM STOP
5806247 4 HEX HEAD CAP SCREW
5806377 4 HEX NUT
19 0404811
0401450
16
1
2” DIAMETER WHEEL KIT*
2” DIAMETER WHEEL BAG (16PC SET)*
20 0400828 TRACK SPLICE PLATE
21 7303600 1 SHEAVE
5806326 1 CARRIAGE BOLT
5806370 1 LOCKNUT
5800831 TRACK SPLICE PLATE NUT & BOLT 1ea.
0482800
TRACK SPLICE PLATE KIT consisting of: 2
splice plates, 8 ea. nut & bolt
0401498
TRACK SWIVEL SHOE CONVERSION KIT*
consisting of: 2 shoes & 2 mounting brackets
* HARDWARE INCLUDED
