2 SPECIFICATIONS
2.1 HOIST SPECIFICATIONS
MODEL
PRO400
Load capacity 400 lbs.
Lift speed 110 fpm
Platform size 24 in. x 28 in.
Track (3 3/4” side rail) 24 in. width
Wire rope 5/32-in. diameter, 7 x 19 galvanized aircraft wire rope
Note that platform speeds and capacities are average and are based on 5/32 inch wire rope diameter. As wire rope builds
up on drum, lifting speed increases and lifting capacity decreases in direct proportion to drum diameter.
2.2 COMPLETE SYSTEM SPECIFICATIONS
16 foot: Includes PRO Drive, Platform assembly, 16-foot aluminum Track with shoes.
28 foot: Includes PRO Drive, Platform assembly, 16-foot aluminum Track with shoes, additional 8 foot and 4 foot Track
sections with splice plates.
44 foot: Includes PRO Drive, Platform assembly, 16 foot aluminum Track with shoes, additional 16 foot, 8 foot, and 4
foot track sections with splice plates, Telescoping track support.
2.3 NAMEPLATE AND SERIAL NUMBER TAG
It is important to identify your hoist completely and accurately whenever ordering spare parts or requesting assistance in
service. The platform hoist nameplate is located on the platform main frame. The label shows the model number, serial
number and the capacity rating. The platform hoist label should appear as the sample nameplate shown in Figure 2-1.
Record the model and serial numbers, and capacity rating for future reference.
HOIST
CAP. lbs.
MODEL
SERIAL NO.
Figure 2-1.
PRO400 Platform Hoist Product Nameplate
MODEL__________________________________
SERIAL NUMBER_________________________
CAPACITY RATING_______________________
