TM090 12-26 Series II CFGWH Service Instructions
REV AB – Issued February 2019
This document is stored and maintained electronically by Rheem Technical Support. All printed copies are deemed “uncontrolled”
Deluxe Controller Functions
Press once to turn on the controller. The button will glow when
the controller is on. A controller cannot be turned on if water is
flowing from a hot tap. Press the button to turn off the
controller. A controller can be turned off whilst water is flowing.
Initiates Bath-Fill mode and once pressed will display the last
used Bath-Fill water volume in litres and the last used Bath-Fill
temperature in °C. The displayed Bath-Fill water volume and
temperature can be adjusted by using the Bath-Fill water
volume and temperature control buttons located beneath the
hinged panel
Bath-Fill operating light
Illuminates whenever Bath-Fill mode is in operation.
Bath-Fill Temperature
(up button)
Increases the Bath-Fill temperature setting.
Decreases the Bath-Fill temperature setting.
Increases the Bath-Fill water volume setting in increments of
10 litres up to 500 litres. A further setting of 990 litres can be
selected
Decreases the Bath-Fill water volume setting
When pressed sounds a message or alert tone on the Kitchen
Controller indicating that assistance is required in the
bathroom.
Displays the selected Bath-Fill water volume in litres. The
quantity of water can be adjusted using the Bath-Fill Water
Volume adjustment buttons located beneath the hinged panel
Illuminates on all controllers when hot water is flowing
Illuminates when that controller is ‘active’. The Bathroom
controller when turned on, have priority over the Kitchen
controller. Priority means that a controller has control of the
water heater temperature setting. The water temperature
setting can only be adjusted by the controller that is displaying
the ACTIVE message.
Displays the current temperature setting on all controllers in
°C when any controller is on. If all controllers are off the display
remains blank.
Increases the general purpose temperature setting.
Decreases the general purpose temperature setting.
