Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
RGFG Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1318AJ1 RGFG-06?MCK?
RCF2417HTAM 18000 [5.3] 12800 [3.8] 5200 [1.5] 14.5 12 575 [271.4] 7507412
RCF2417MTAM 18000 [5.3] 12800 [3.8] 5200 [1.5] 14.5 12 575 [271.4] 7507427
RCF2417STAM 17900 [5.2] 13400 [3.9] 4500 [1.3] 14.5 12 575 [271.4] 7507443
RCF2421MTAM 18000 [5.3] 12800 [3.8] 5200 [1.5] 14.5 12 575 [271.4] 7507475
RA1318AJ1 RGFG-07?MCK?
RCF2417HTAM 18300 [5.4] 13200 [3.9] 5100 [1.5] 14.5 12 650 [306.8] 7507413
RCF2417MTAM 18200 [5.3] 13100 [3.8] 5100 [1.5] 14.5 12 650 [306.8] 7507428
RCF2417STAM 18200 [5.3] 13800 [4.0] 4400 [1.3] 14.5 12 650 [306.8] 7507444
RCF2421MTAM 18200 [5.3] 13100 [3.8] 5100 [1.5] 14.5 12 650 [306.8] 7507476
RA1318AJ1 RGFG-09?ZCM? RCF2421MTAM 18400 [5.4] 13300 [3.9] 5100 [1.5] 14.5 12 675 [318.6] 7507477
RA1318AJ1 RGFG-10?ZCM? RCF2421MTAM 18000 [5.3] 12800 [3.8] 5200 [1.5] 14.5 12 600 [283.2] 7507478
RA1324AJ1 RGFG-06?MCK?
RCF2417HTAM 24000 [7.0] 17100 [5.0] 6900 [2.0] 14 11.5 800 [377.6] 7507618
RCF2417MTAM 24000 [7.0] 17100 [5.0] 6900 [2.0] 14 11.5 800 [377.6] 7507636
RCF2417STAM 23800 [7.0] 17800 [5.2] 6000 [1.8] 14 11.5 800 [377.6] 7507655
RCF2421MTAM 24000 [7.0] 17100 [5.0] 6900 [2.0] 14 11.5 800 [377.6] 7507696
RA1324AJ1 RGFG-07?MCK?
RCF2417HTAM 24200 [7.1] 17500 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507619
RCF2417MTAM 24200 [7.1] 17500 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507637
RCF2417STAM 24000 [7.0] 18000 [5.3] 6000 [1.8] 14 11.5 800 [377.6] 7507656
RCF2421MTAM 24200 [7.1] 17500 [5.1] 6700 [2.0] 14 11.5 850 [401.2] 7507697
RA1324AJ1 RGFG-09?ZCM? RCF2421MTAM 24000 [7.0] 17000 [5.0] 7000 [2.1] 14.5 12 775 [365.8] 7507698
RA1324AJ1 RGFG-10?ZCM? RCF2421MTAM 23600 [6.9] 16500 [4.8] 7100 [2.1] 14.5 12 725 [342.2] 7507699
RA1330AJ1 RGFG-06?MCK?
RCF3617STAM 28000 [8.2] 20500 [6.0] 7500 [2.2] 14 11.5 800 [377.6] 7507853
RCF3621MTAM 29600 [8.7] 21000 [6.2] 8600 [2.5] 14.5 12 800 [377.6] 7507873
RCF3621STAM 28000 [8.2] 20500 [6.0] 7500 [2.2] 14 11.5 800 [377.6] 7507904
RA1330AJ1 RGFG-07?MCK?
RCF3617STAM 28200 [8.3] 20900 [6.1] 7300 [2.1] 14 11.5 850 [401.2] 7507854
RCF3621MTAM 29800 [8.7] 21400 [6.3] 8400 [2.5] 14.5 12 850 [401.2] 7507874
RCF3621STAM 28200 [8.3] 20900 [6.1] 7300 [2.1] 14 11.5 850 [401.2] 7507905
RA1330AJ1 RGFG-09?ZCM?
RCF3621MTAM 30400 [8.9] 22500 [6.6] 7900 [2.3] 14.5 12 1025 [483.7] 7507875
RCF3621STAM 29000 [8.5] 22100 [6.5] 6900 [2.0] 14 11.5 975 [460.1] 7507906
RCF3624HTAM 31200 [9.1] 22900 [6.7] 8300 [2.4] 15.1 12.5 975 [460.1] 7507931
RCF3624MTAM 30400 [8.9] 22500 [6.6] 7900 [2.3] 14.5 12 1025 [483.7] 7507955
RA1330AJ1 RGFG-10?ZCM?
RCF3621MTAM 30600 [9.0] 22900 [6.7] 7700 [2.3] 14.5 12 1050 [495.5] 7507876
RCF3621STAM 28800 [8.4] 22000 [6.4] 6800 [2.0] 14 11.5 1000 [471.9] 7507907
RCF3624HTAM 31200 [9.1] 23200 [6.8] 8000 [2.3] 15.1 12.5 1050 [495.5] 7507932
RCF3624MTAM 30600 [9.0] 22900 [6.7] 7700 [2.3] 14.5 12 1050 [495.5] 7507956
RA1330AJ1 RGFG-12?RCM?
RCF3624HTAM 31200 [9.1] 22900 [6.7] 8300 [2.4] 15.5 13 975 [460.1] 7507933
RCF3624MTAM 30600 [9.0] 22600 [6.6] 8000 [2.3] 15 12.5 975 [460.1] 7507957
RA1336AC1 RGFG-06?MCK?
RCF3617STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508198
RCF3621MTAM 37000 [10.8] 25100 [7.4] 11900 [3.5] 14 11.5 1000 [471.9] 7508218
RCF3621STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508249
RA1336AC1 RGFG-07?MCK?
RCF3617STAM 34600 [10.1] 24300 [7.1] 10300 [3.0] 13 11 1000 [471.9] 7508199
RCF3621MTAM 36800 [10.8] 24900 [7.3] 11900 [3.5] 14 11.5 1000 [471.9] 7508219
RCF3621STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508250
RA1336AC1 RGFG-09?ZCM?
RCF3621MTAM 37800 [11.1] 26900 [7.9] 10900 [3.2] 14 11.5 1200 [566.3] 7508220
RCF3621STAM 34800 [10.2] 24700 [7.2] 10100 [3.0] 13.5 11.5 1025 [483.7] 7508251
RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 14.5 12 1200 [566.3] 7508278
RCF3624MTAM 37800 [11.1] 26900 [7.9] 10900 [3.2] 14 11.5 1200 [566.3] 7508305
[ ] Designates Metric Conversions
