Rheem RA13 Series User Manual

23
Air
Performance Data
RA13 Series
Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
RGFG Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1336AC1 RGFG-10?ZCM?
RCF3621MTAM 37200 [10.9] 25300 [7.4] 11900 [3.5] 14.5 12 1000 [471.9] 7508221
RCF3621STAM 35000 [10.3] 25000 [7.3] 10000 [2.9] 13.5 11.5 1050 [495.5] 7508252
RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 14.5 12 1200 [566.3] 7508279
RCF3624MTAM 37200 [10.9] 25300 [7.4] 11900 [3.5] 14.5 12 1000 [471.9] 7508306
RA1336AC1 RGFG-12?RCM?
RCF3624HTAM 38000 [11.1] 26200 [7.7] 11800 [3.5] 15.1 12.5 1025 [483.7] 7508280
RCF3624MTAM 37200 [10.9] 25500 [7.5] 11700 [3.4] 14.5 12 1025 [483.7] 7508307
RA1336AJ1 RGFG-06?MCK?
RCF3617STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508564
RCF3621MTAM 37000 [10.8] 25100 [7.4] 11900 [3.5] 14 11.5 1000 [471.9] 7508584
RCF3621STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508615
RA1336AJ1 RGFG-07?MCK?
RCF3617STAM 34600 [10.1] 24300 [7.1] 10300 [3.0] 13 11 1000 [471.9] 7508565
RCF3621MTAM 36800 [10.8] 24900 [7.3] 11900 [3.5] 14 11.5 1000 [471.9] 7508585
RCF3621STAM 34800 [10.2] 24500 [7.2] 10300 [3.0] 13 11.5 1000 [471.9] 7508616
RA1336AJ1 RGFG-09?ZCM?
RCF3621MTAM 37800 [11.1] 26900 [7.9] 10900 [3.2] 14 11.5 1200 [566.3] 7508586
RCF3621STAM 34800 [10.2] 24700 [7.2] 10100 [3.0] 13.5 11.5 1025 [483.7] 7508617
RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 14.5 12 1200 [566.3] 7508644
RCF3624MTAM 37800 [11.1] 26900 [7.9] 10900 [3.2] 14 11.5 1200 [566.3] 7508671
RA1336AJ1 RGFG-10?ZCM?
RCF3621MTAM 37200 [10.9] 25300 [7.4] 11900 [3.5] 14.5 12 1000 [471.9] 7508587
RCF3621STAM 35000 [10.3] 25000 [7.3] 10000 [2.9] 13.5 11.5 1050 [495.5] 7508618
RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 14.5 12 1200 [566.3] 7508645
RCF3624MTAM 37200 [10.9] 25300 [7.4] 11900 [3.5] 14.5 12 1000 [471.9] 7508672
RA1336AJ1 RGFG-12?RCM?
RCF3624HTAM 38000 [11.1] 26200 [7.7] 11800 [3.5] 15.1 12.5 1025 [483.7] 7508646
RCF3624MTAM 37200 [10.9] 25500 [7.5] 11700 [3.4] 14.5 12 1025 [483.7] 7508673
RA1342AC1 RGFG-09?ZCM?
RCF4821STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511569
RCF4824HTAM 41000 [12.0] 27800 [8.1] 13200 [3.9] 14 11.5 1200 [566.3] 7511597
RCF4824STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511625
RA1342AC1 RGFG-10?ZCM?
RCF4821STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511570
RCF4824HTAM 41000 [12.0] 27800 [8.1] 13200 [3.9] 14 11.5 1200 [566.3] 7511598
RCF4824STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511626
RA1342AC1 RGFG-12?RCM?
RCF4824HTAM 41500 [12.2] 28600 [8.4] 12900 [3.8] 14 11.5 1250 [589.9] 7511599
RCF4824STAM 40000 [11.7] 29000 [8.5] 11000 [3.2] 13.5 11.5 1250 [589.9] 7511627
RA1342AJ1 RGFG-09?ZCM?
RCF4821STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511803
RCF4824HTAM 41000 [12.0] 27800 [8.1] 13200 [3.9] 14 11.5 1200 [566.3] 7511831
RCF4824STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511859
RA1342AJ1 RGFG-10?ZCM?
RCF4821STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511804
RCF4824HTAM 41000 [12.0] 27800 [8.1] 13200 [3.9] 14 11.5 1200 [566.3] 7511832
RCF4824STAM 39500 [11.6] 28200 [8.3] 11300 [3.3] 13.5 11.5 1200 [566.3] 7511860
RA1342AJ1 RGFG-12?RCM?
RCF4824HTAM 41500 [12.2] 28600 [8.4] 12900 [3.8] 14 11.5 1250 [589.9] 7511833
RCF4824STAM 40000 [11.7] 29000 [8.5] 11000 [3.2] 13.5 11.5 1250 [589.9] 7511861
RA1348AC1 RGFG-09?ZCM?
RCF4821STAM 46500 [13.6] 31700 [9.3] 14800 [4.3] 13 11 1275 [601.7] 7508930
RCF4824HTAM 49000 [14.4] 33000 [9.7] 16000 [4.7] 13 11.5 1400 [660.7] 7508947
RCF4824STAM 46500 [13.6] 31700 [9.3] 14800 [4.3] 13 11 1275 [601.7] 7508988
RA1348AC1 RGFG-10?ZCM? RCF4824HTAM 49000 [14.4] 33000 [9.7] 16000 [4.7] 13 11.5 1400 [660.7] 7508948
RA1348AC1 RGFG-12?RCM?
RCF4824HTAM 49500 [14.5] 33800 [9.9] 15700 [4.6] 13.5 11.5 1450 [684.3] 7508949
RCF4824STAM 46500 [13.6] 31600 [9.3] 14900 [4.4] 13 11.5 1250 [589.9] 7508991
RA1348AJ1 RGFG-09?ZCM?
RCF4821STAM 46500 [13.6] 31700 [9.3] 14800 [4.3] 13 11 1275 [601.7] 7509155
RCF4824HTAM 49000 [14.4] 33000 [9.7] 16000 [4.7] 13 11.5 1400 [660.7] 7509172
RCF4824STAM 46500 [13.6] 31700 [9.3] 14800 [4.3] 13 11 1275 [601.7] 7509197
[ ] Designates Metric Conversions
