Performance Data
RA13 Series
Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
RGFG Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1348AJ1 RGFG-10?ZCM? RCF4824HTAM 49000 [14.4] 33000 [9.7] 16000 [4.7] 13 11.5 1400 [660.7] 7509173
RA1348AJ1 RGFG-12?RCM?
RCF4824HTAM 49500 [14.5] 33800 [9.9] 15700 [4.6] 13.5 11.5 1450 [684.3] 7509174
RCF4824STAM 46500 [13.6] 31600 [9.3] 14900 [4.4] 13 11.5 1250 [589.9] 7509198
RA1360AC1 RGFG-09?ZCM?
RCF6024HTAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509299
RCF6024STAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509323
RA1360AC1 RGFG-10?ZCM?
RCF6024HTAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509300
RCF6024STAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509324
RA1360AC1 RGFG-12?RCM?
RCF6024HTAM 55500 [16.3] 38000 [11.1] 17500 [5.1] 13 11 1450 [684.3] 7509301
RCF6024STAM 55500 [16.3] 38000 [11.1] 17500 [5.1] 13 11 1450 [684.3] 7509325
RA1360AJ1 RGFG-09?ZCM?
RCF6024HTAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509421
RCF6024STAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509445
RA1360AJ1 RGFG-10?ZCM?
RCF6024HTAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509422
RCF6024STAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509446
RA1360AJ1 RGFG-12?RCM?
RCF6024HTAM 55500 [16.3] 38000 [11.1] 17500 [5.1] 13 11 1450 [684.3] 7509423
RCF6024STAM 55500 [16.3] 38000 [11.1] 17500 [5.1] 13 11 1450 [684.3] 7509447
RGGE Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1330AJ1 RGGE-09?ZCM? RCF3624HTAM 31200 [9.1] 23000 [6.7] 8200 [2.4] 15.5 13 1000 [471.9] 7507934
RA1330AJ1 RGGE-10?ZCM? RCF3624HTAM 31400 [9.2] 23400 [6.9] 8000 [2.3] 15.1 12.5 1050 [495.5] 7507935
RA1330AJ1 RGGE-12?RCM? RCF3624HTAM 31400 [9.2] 23400 [6.9] 8000 [2.3] 15.5 13 1050 [495.5] 7507936
RA1336AC1 RGGE-09?ZCM? RCF3624HTAM 38000 [11.1] 26200 [7.7] 11800 [3.5] 15 12.5 1025 [483.7] 7508281
RA1336AC1 RGGE-10?ZCM? RCF3624HTAM 39000 [11.4] 28400 [8.3] 10600 [3.1] 14.5 12 1275 [601.7] 7508282
RA1336AC1 RGGE-12?RCM? RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 15.1 12.5 1200 [566.3] 7508283
RA1336AJ1 RGGE-09?ZCM? RCF3624HTAM 38000 [11.1] 26200 [7.7] 11800 [3.5] 15 12.5 1025 [483.7] 7508647
RA1336AJ1 RGGE-10?ZCM? RCF3624HTAM 39000 [11.4] 28400 [8.3] 10600 [3.1] 14.5 12 1275 [601.7] 7508648
RA1336AJ1 RGGE-12?RCM? RCF3624HTAM 39000 [11.4] 28000 [8.2] 11000 [3.2] 15.1 12.5 1200 [566.3] 7508649
RA1342AC1 RGGE-09?ZCM? RCF4824HTAM 41500 [12.2] 28600 [8.4] 12900 [3.8] 14 11.5 1250 [589.9] 7511600
RA1342AC1 RGGE-10?ZCM? RCF4824HTAM 41500 [12.2] 28300 [8.3] 13200 [3.9] 14 11.5 1200 [566.3] 7511601
RA1342AC1 RGGE-12?RCM? RCF4824HTAM 42000 [12.3] 29700 [8.7] 12300 [3.6] 14 11.5 1375 [648.9] 7511602
RA1342AJ1 RGGE-09?ZCM? RCF4824HTAM 41500 [12.2] 28600 [8.4] 12900 [3.8] 14 11.5 1250 [589.9] 7511834
RA1342AJ1 RGGE-10?ZCM? RCF4824HTAM 41500 [12.2] 28300 [8.3] 13200 [3.9] 14 11.5 1200 [566.3] 7511835
RA1342AJ1 RGGE-12?RCM? RCF4824HTAM 42000 [12.3] 29700 [8.7] 12300 [3.6] 14 11.5 1375 [648.9] 7511836
RA1348AC1 RGGE-09?ZCM? RCF4824HTAM 49500 [14.5] 33500 [9.8] 16000 [4.7] 13 11.5 1400 [660.7] 7508950
RA1348AC1 RGGE-10?ZCM? RCF4824HTAM 49500 [14.5] 33500 [9.8] 16000 [4.7] 13 11.5 1400 [660.7] 7508951
RA1348AC1 RGGE-12?RCM? RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 13.5 11.5 1375 [648.9] 7508952
RA1348AJ1 RGGE-09?ZCM? RCF4824HTAM 49500 [14.5] 33500 [9.8] 16000 [4.7] 13 11.5 1400 [660.7] 7509175
RA1348AJ1 RGGE-10?ZCM? RCF4824HTAM 49500 [14.5] 33500 [9.8] 16000 [4.7] 13 11.5 1400 [660.7] 7509176
RA1348AJ1 RGGE-12?RCM? RCF4824HTAM 49500 [14.5] 33300 [9.8] 16200 [4.7] 13.5 11.5 1375 [648.9] 7509177
RA1360AC1 RGGE-09?ZCM? RCF6024HTAM 55500 [16.3] 37700 [11.0] 17800 [5.2] 13 11 1400 [660.7] 7509302
RA1360AC1 RGGE-10?ZCM? RCF6024HTAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509303
RA1360AC1 RGGE-12?RCM? RCF6024HTAM 56500 [16.6] 40000 [11.7] 16500 [4.8] 13 11 1575 [743.3] 7509304
RA1360AJ1 RGGE-09?ZCM? RCF6024HTAM 55500 [16.3] 37700 [11.0] 17800 [5.2] 13 11 1400 [660.7] 7509424
RA1360AJ1 RGGE-10?ZCM? RCF6024HTAM 55000 [16.1] 37200 [10.9] 17800 [5.2] 13 11 1400 [660.7] 7509425
RA1360AJ1 RGGE-12?RCM? RCF6024HTAM 56500 [16.6] 40000 [11.7] 16500 [4.8] 13 11 1575 [743.3] 7509426
[ ] Designates Metric Conversions
