FIGURE 63
NAVIGATE TO DESIRED USER MENU AND SELECT.
FIGURE 62
NAVIGATE TO FURNACE AND SELECT.
VIEWING FURNACE USER
MENUS WITH THE (-)HC-
TST550CMMS THERMOSTAT
To enter a particular user menu on
the (-)HC-TST550CMMS, full color
communicating thermostat follow
the directions below.
Use the section of this manual
titled
CCoommmmuunniiccaattiinngg SSyysstteemmss
under the sub-section titled
UUsseerr
MMeennuuss
to navigate through the
user menus.
FIGURE 60
ENTER THE ADVANCED INSTALLER MENU.
FIGURE 61
NAVIGATING TO COMMUNICATING DEVICES AND SELECT.
3. From the devices
listed, use the up
and down arrow
keys to highlight the
selection titled
FFuurrnnaaccee
. Next,
Press the “
MM
” Key.
The next screen
below will appear.
4. The furnace menu
options will appear.
Use the up and down
arrow keys to select
the desired menu.
Next, press “
MM
” to
enter the desired
menu. Next, the next
screen below will
appear.
FIGURE 64
NAVIGATE THE USER MENUS USING UP AND DOWN ARROW KEYS.
5. Use the up and down
arrow keys to view the
menu items.
6. To escape from this
menu, press the
EEnntteerr
(to return to the fur-
nace user menus) or
HHoommee
button or just
wait a few minutes
and the main screen
will appear again.
2. The
AADDVVAANNCCEEDD
IINNSSTTAALLLLEERR MMEENNUU
is displayed. Use
the up and down
arrow keys to high-
light
CCoommmmuunniiccaattiinngg
DDeevviicceess
. Next,
press the “
MM
” key.
The next screen
below will appear.
1. From the main
screen, press the left
and right arrow keys
together at the same
time for at least 3
seconds. The next
screen below will
appear.
Home
Enter
Home
Enter
Home
Enter
Home
Enter
91
