52
• External Filter Base RXHF- (See Figure 42)
Model Cabinet Size Filter Size Part Number AB
17 16 x 20 [406 x 508] RXHF-17 15.70 17.50
21 20 x 20 [508 x 508] RXHF-21 19.20 21.00
24 25 x 20 [635 x 508] RXHF-24 22.70 25.50
A
ccommodate
1
” or 2”
f
ilter
FIGURE 42
E
XTERNAL FILTER BASE: RXHF-
