Nominal Auxiliary Horizontal Overflow
Cooling Pan Accessory
Capacity Ton Model Number
1
1
/2 - 3 RXBM-AC48
3
1
/2 - 5 RXBM-AC61
• Horizontal Adapter Kit RXHH-
This horizontal adapter kit is used to convert Upflow/Downflow only models to hori-
zontal flow. See the following table to order proper horizontal adapter kit.
• Auxiliary Horizontal Unit Overflow Pan Accessory RXBM-
Coil Model
Horizontal Adapter Kit Horizontal Adapter Kit
Model Number (Single Qty.) Model Number (10-pak Qty.)
2414 RXHH-A01 RXHH-A01x10
2417 RXHH-A02 RXHH-A02x10
3617/3621 RXHH-A03 RXHH-A03x10
3821/4821/4824 RXHH-A04 RXHH-A04x10
6024 RXHH-A05 RXHH-A05x10
3621H/4821S/
RXHH-A06 RXHH-A06x10
6021M
• External Filter Rack: RXHF-B (See Figure 43)
Model Cabinet Size Filter Size Part Number AB
17 16 x 20 RXHF-B17 16.90 20.77
21 20 x 20 RXHF-B21 20.40 20.77
24 25 x 20 RXHF-B24 25.00 21.04
Accommodate
1
” filter
FIGURE 43
EXTERNAL FILTER RACK: RXHF- B17, B21, B24
