ASSEMBLY
TM60/72/84/100 02/11 Assembly Section 3-2
© 2011 Alamo Group Inc.
ASSEMBLY
The TM60, TM72, TM84 and TM100 mowers will attach to most tractors with Cat. I Three-Point hitch and a 540
RPM PTO. DO NOT EXCEED HORSEPOWER RECOMMENDATIONS.
Operating with PTO speed over 540 RPM can cause excessive vibration with subsequent
machine failure which can cause serious injury or even death. Never exceed 600 RPM.
DEALER SET-UP INSTRUCTIONS
Assembly of this mower is the responsibility of the Rhino dealer. The mower should be delivered to the owner
completely assembled, lubricated, and adjusted for normal cutting conditions.
Set up mower as received from the factory with these instructions. Remove mower from pallet. Lay parts out to
make location easy. Refer to parts lists and exploded view drawings for more detail.
This mower is shipped partially assembled. Assembly will be easier if components are aligned and loosely
assembled before tightening hardware.
Always use personal protection devices such as eye and ear protectors during assembly.
