FIT SLIM
PHOTOCELLS for the wall-installation code ACG8032
FIT SLIM photocells have synchronism function in AC current and
ranges of 20 m.
Y
ou can fit many couples close together thanks to the synchronising
circuit.
Add the SYNCRO TRANSMITTER TX SLIM SYNCRO code ACG8029
for more than 2 photocells couples (up to 4).
SPARK
In order to make the systems mentioned above give the best
performances, you need to install an antenna tuned on the frequency of
the radio receiver installed.
N.B. Pay attention to not let the central wire of the cable to came
Into contact with the external copper sheath, since this would
prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can
reach it.
SPARK ANTENNA 91 code ACG5454
SPARK ANTENNA 433 code ACG5452
SPARK BLINKER WITH IN-BUILT INTERMITTENT CARD
code ACG7059
MECHANICAL BOLT
For 2-leaf gates to latch closed gate to the ground. code ACG5000
PUSH-BUTTON FLAT
Connection to motor code ACG2012
Connection to control panel code ACG2013
SHIELDED WIRE
It is compulsory to use shielded cable for the encoder in order to
guarantee the correct operation of the control board.
The screen of the ENCODER cable must be earth grounded at one
end (not to the card GND), and at the opposite end the screen must
be free (conductor not connected). code ACG2133
GG
BB
PAIR OF COLUMNS FOR FIT SLIM
code
ACG8065
