Printer Driver > Maintaining the Printer Using Utilities > Nozzle Check
Nozzle Check
Follow the procedure below to check whether the print-head nozzles are clogged up or not by printing a nozzle check
test pattern.
● To check the printed test pattern, proceed to step .
Open the printer properties dialog box.
Click the [Maintenance] tab.
Click [Nozzle Check].
Click [Next >].
Check that A4/Letter size paper is loaded in the paper tray.
Click [Next >].
Check the printed test pattern.
Normal
When print-heads are clogged
Click [Finish].
● If the printed test pattern is not clear, select the [Clean Print-heads (Normal)] check box, and then click [Next >].
