Ricoh Aficio MP 4002SP Service Manual

Main SP Tables-9
SM 5-193 D129/D130
Service
Tables
1000-Sheet Finisher (D588)
6139 Bit Description
Reading
0 1
001 Entrance Sensor Paper detected
No paper
detected
002
Shift Exit Sensor
(Lower Tray Exit Sensor)
No paper detected Paper detected
003
Staple Entrance Sensor
(Stapler Tray Entrance Sensor)
Paper detected
No paper
detected
004
Staple Moving HP Sensor
(Stapler HP Sensor)
Not HP HP
005
Jogger HP Sensor
(Jogger Fence HP Sensor)
Not HP HP
006 Stack Feed-out Belt HP Sensor HP Not HP
007 Staple Tray Paper Sensor No paper detected Paper detected
008
Staple Rotation Sensor
(Staple Rotation HP Sensor)
Not HP HP
009 Staple Sensor Staple detected
No staple
detected
010 Staple READY Detection Staple detected
No staple
detected
011
Exit Guide Plate HP
(Exit Guide Plate HP Sensor)
Not HP HP
012 Shift HP Sensor Not HP HP
013
Paper Sensor
(Stack Height Sensor)
No output tray
detected
Output tray
detected
014
Tray Lower Sensor
(Lower Tray Lower Limit Sensor)
Lower limit Not lower limit
