Ricoh Aficio SP 6330N - Dip Switch Settings

127
R
i
c
o
h
C
o
.
L
t
d
.
h
t
t
p
:
/
/
w
w
w
.
r
i
c
o
h
.
c
o
m
/
M047 Series Training - Kriss-P2 /Model Kr-P2
Slide 127
PC2100CN702
CN707
CN708
CN709
SW1 DIPSW IC 1 9
LED1
Dip Switches
(Controller Board)
! DIP Switch 1 (Bit 1)
on controller board
is used for error
recovery if firmware
updating procedure
fails.
! Note: Default
settings of DIP
Switches are as
follows
" "No.1: ON"
" "No. 2 to 4: OFF"
» Not used on this
model
.
