Ricoh Aficio SP C830DN Specifications

SYStem SpecificationS
Ricoh Aficio SP C830DN/SP C831DN
R3413
Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355, 1-800-63-RICOH
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. ©2012 Ricoh Americas Corporation. All rights
reserved. The content of this document, and the appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products
are shown with optional features. While care has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or
adequacy of the information contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services,
and the conditions and factors affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
Specifications
SP C830DN Part # 430709
SP C831DN Part # 430713
Configuration Desktop Color Laser Beam Printer
Technology Laser-beam scanning & electrophotographic
printing with dual component toner
development, 4-drum tandem method
Operation Panel 4.3" color touch screen with integrated USB
2.0 host port and SD card slot
Printing Speed SP C830DN: 45-ppm B&W and full-color
SP C831DN: 55-ppm B&W and full-color
Warm-Up Time SP C830DN: 29 seconds or less
SP C831DN: 25 seconds or less
First Print Speed SP C830DN: Black & White: 3.7 seconds or
less; Full Color: 5.7 seconds or less
SP C831DN: Black & White: 3.4 seconds or
less; Full Color: 5.1 seconds or less
Duplex Print Speed Near 100% productivity for all paper sizes
Print Resolution 300 x 300-dpi (1-bit), 600 x 600-dpi (2-bit)
(Default), 600 x 600-dpi (1-bit, 4-bit), 1200 x
1200 dpi (1-bit)
Standard Paper Supply 550 x 2 Paper Tray + 100-Sheet Bypass Tray
(1,200 sheets total capacity)
Maximum Paper Supply 4,400 sheets (Standard Trays 1 & 2 + 2,000-
Sheet LCT + 1,200-Sheet Side LCT + 100-
Sheet Bypass Tray)
Output Capacity Standard: 500 sheets, face down (8.5" x 11"
or smaller); 250 sheets, face down (8.5" x 14"
or larger); Maximum: Up to 4,000 sheets with
Finisher, Bridge Unit and 4-Bin Mailbox
Paper Sizes Standard Tray 1: Fixed for Letter (8.5" x 11")
(216 x 279mm), A4, A5
Standard Tray 2 and Optional Paper Feed
Units: User adjustable for Letter (8.5" x 11"),
Legal (8.5" x 14"), Exec (10.5" x 7.25"),
Ledger (11" x 17"), A3, A4, A5; Custom
Sizes: 5.83" x 7.17" – 11.69" x 17" (148 x
182mm – 297 x 432mm)
Envelopes: Com10, C5
Bypass Tray: User adjustable for 5.5" x 8.5"
– 11" x 17" (140 x 216mm – 279 x 432mm);
Custom Sizes: 3.55" x 5.83" – 12" x 49.6"
(90 x 148mm – 305 x 1260mm)
Envelopes: Com10, Monarch, C5, C6, DL
Optional 2,000-Sheet LCT and Optional
1,200-Sheet Side LCT: Fixed for Letter (8.5" x
11") (216 x 279mm), A4
When Duplexing: 3.55" x 5.83" – 11.69" x 17"
(90 x 148mm x 279 x 432mm)
Paper Weights Standard Trays, Optional Paper Feed Units,
and Optional 2,000-Sheet LCT: 14 – 68 lb.
Bond/ 140 lb. Index (52 – 256 g/m
2
)
Bypass Tray: 14 – 82 lb. Bond/170 lb. Index
(52 – 300 g/m
2
)
Optional 1,200-Sheet Side LCT: 16 – 58 lb.
Bond/120 lb. Index (60 – 216 g/m
2
)
Duplex Unit: 14 – 45 lb. Bond/90 lb. Index
(52 – 169 g/m
2
)
Paper Types All Sources: Plain Paper, Recycled Paper,
Color Paper, Letterhead, Special Paper 1-3,
Card Stock, Bond Paper, Preprinted Paper
Envelopes: Com10 and C5 envelopes can be
fed using Standard Tray 2, Bypass Tray and
Optional Paper Feed Units
Bypass Only: Labels, OHP, Coated Paper
Envelopes: Com10, Monarch, C5, C6, DL
Automatic Duplex Standard
Dimensions (WxDxH) Base Model: 26.4" x 26.9" x 25.2" (670 x 684
x 640 mm)
Weight Base Model: Less than 213 lb. (97 kg)
Power Requirements 120 – 127V, 60Hz
Power Consumption 1.1 W (Sleep Mode)
TEC SP C830DN – 2.033 kWH/week
SP C831DN – 2.638 kWH//week
Operating 1,584 W or less; Sleep: 1.2 W or less
Print Controller Specifications (Standard)
CPU SP C830DN: Intel Celeron-M 600MHz
SP C831DN: Intel Celeron-M 1GHz
Memory Standard 512 MB RAM/Maximum 1.5 GB
RAM
Hard Disk Drive SP C830DN: Optional 250 GB
SP C831DN: Standard 250 GB
(both models include standard Hard Disk Drive
Encryption Unit and DataOverwriteSecurity
System)
Printer Languages Standard: PCL 5c, PCL 6, Adobe
®
PostScript
®
3
™
, PDF Direct Print, Direct Media
Print (JPEG/TIFF)
Optional: PictBridge, Genuine IPDS Host
Print, XPS (via download), Universal Driver (via
download)
Fonts Standard: PCL: 45 + 13 International,
PostScript3/PDF: 136
Optional: IPDS: 108
Standard Interfaces 10/100Base-TX Ethernet, High Speed USB
2.0 Type B, Dual USB 2.0 Host Type A, USB
2.0 Type A/SD Card Slot integrated into
Control Panel (for Print From Portable Media)
Optional Interfaces* Gigabit Ethernet (1000Base-T) Type D, IEEE
802.11a/g Wireless LAN Type L, IEEE 1284/
ECP Parallel Interface Type A
Network Protocols Standard: TCP/IP (IPv6)
Optional: IPX/SPX
Operating Systems Windows XP, Vista, 7, Server 2003/R2, Server
2008/R2; Citrix Presentation Server 4.5, Citrix
XenApp 5.0+; Mac OS X v10.4 – 10.7; SAP
R/3; Novell NetWare Server 6.5 (option is
required), UNIX (Using Ricoh UNIX filter): Sun
Solaris 2.6/7/8/9/10, HP-UX 10.x/11.x/11i
v2/11i v3, SCO OpenServer 5.0.6/5.0.7/6.0,
RedHat Linux Enterprise 4/5/6, IBM AIX 5L
version 5.3/6.1/7.1
Software Utilities SmartDeviceMonitor for Admin and Client;
SmartDeviceMonitor for Admin Accounting
Report Package; Web SmartDeviceMonitor;
Web Image Monitor; Remote Communication
Gate Type S; @Remote
Controller and Memory Options
IEEE 1284 Interface Board Type A – Part # 411699
IEEE 802.11a/g Wireless LAN Type L – Part # 403000
Gigabit Ethernet Board Type D – Part # 407087
Camera Direct Print Card Type J – Part # 416006
VM Card Type U – Part # 416163
IPDS Unit Type C830 – Part # 407081
512 MB Memory Unit Type J – Part # 004165MIU
1 GB Memory Unit Type O – Part # 007097MIU
250 GB Hard Disk Drive Type C830 (SP C830DN only) – Part # 007098MIU
Document Server Specifications*
Total HDD Capacity 250 GB (shared with other functions)
Max. Stored Documents 3,000 files
Max. Pages/Document 1,000 page
Max. Stored Page Capacity Approx. 9,000 pages total
*Standard for SP C831DN; Optional for SP C830DN
Hardware Accessories
550 x 1 Paper Feed Unit (PB3120) – Part # 415794
Paper Capacity 550 sheets
Paper Sizes 7.25" x 10.5" – 11" x 17", A3, A4, A5
Envelopes: Com10, C5
Paper Weights
14 – 68 lb. Bond/140 lb. Index (52 – 256 g/m
2
)
550 x 2 Paper Feed Unit (PB3130) – Part # 415793
Paper Capacity 1,100 sheets
Paper Sizes 7.25" x 10.5" – 11" x 17", A3, A4, A5
Envelopes: Com10, C5
Paper Weights 14 – 68 lb. Bond/140 lb. Index (52 – 256 g/m
2
)
2,000-Sheet Large Capacity Tray (LCT) (PB3140) – Part # 415795
Paper Capacity 2,000 sheets (1,000 x 2)
Paper Sizes 8.5" x 11", A4
Paper Weights
14 – 68 lb. Bond/140 lb. Index (52 – 256 g/m
2
)
1,200-Sheet Side Large Capacity Tray (LCT) (RT3020)* – Part # 415984
Paper Capacity 1,200 sheets
Paper Sizes 8.5" x 11", A4
Paper Weights
16 – 58 lb. Bond/120 lb. Index (60 – 216 g/m
2
)
*Requires configuration with 550 x 2 Paper Feed Unit (PB3130) or 2,000-Sheet
Large Capacity Tray (PB3140).
Large Cabinet Stand (FAC 52) – Part # 416337
The Large Cabinet Stand (FAC 52) must be selected when the printer main
unit is to be configured with a Finisher, but not a paper supply option.
Caster Table Type D – Part # 415811
The Caster Table Type D is recommended when the main unit is configured
with the 550 x 1 Paper Feed Unit (PB3120).
3,000-Sheet Finisher (SR3120)* – Part # 416008
Modes Shift Sort, Stack, Staple, Optional Hole Punch
Paper Sizes Proof Tray: 5.5" x 8.5" – 11" x 17", A5 – A3
Shift Tray: 5.5" x 8.5" – 11" x 17", A5 – A3
Paper Weights Proof Tray: 14 – 28 lb. Bond (52 –105 g/m
2
)
Shift Tray: 14 – 68 lb. Bond/140 lb. Index
(52 – 256 g/m
2
)
Stack Capacity Proof Tray: 250 sheets (8.5" x 11" or smaller),
50 sheets (8.5" x 14" or larger)
Shift Tray: 3,000 sheets (8.5" x 11"), 1,500
sheets (8.5" x 14" or larger), 500 sheets (5.5"
x 8.5")
Staple Capacity 50 sheets (8.5" x 11" or smaller); 30 sheets
(8.5" x 14" or larger; 30 sheets (Mixed Sizes:
Letter and Ledger)
Staple Paper Sizes 8.5" x 11" – 11" x 17", A4 – A3
Staple Paper Weights 17 – 24 lb. Bond (64 – 90 g/m
2
)
Staple Positions 1 staple/3 positions
2 staples/1 position
Dimensions (WxDxH) 25.9" x 24.1" x 37.8" (657 x 613 x 960 mm)
Weight 119 lb. (54 kg)
Staple Cartridge Capacity 5,000 staples/cartridge
*Requires configuration with Bridge Unit (BU3060) and 550 x 2 Paper Feed Unit
(PB3130), 2,000-Sheet Large Capacity Tray (PB3140), or Large Cabinet Stand
(FAC 52)
2,000-Sheet Booklet Finisher (SR3110)* – Part # 416007
Modes Shift Sort, Stack, Staple, Saddle Stitch,
Optional Hole Punch
Paper Sizes
Proof Tray: 5.5" x 8.5" – 11" x 17", A5 – A3
Shift Tray: 5.5" x 8.5" – 11" x 17", A5 – A3
Booklet Tray: 8.5" x 11", 8.5" x 14", 11" x 17",
A4 – A3
Paper Weights Proof Tray: 14 – 43 lb. Bond / 90 lb. Index
(52 – 163 g/m
2
)
Shift Tray: 14 – 68 lb. Bond / 140 lb. Index
(52 – 256 g/m
2
)
Booklet Tray: 17 – 24 lb. Bond (64 – 90 g/m
2
)
Stack Capacity Proof Tray: 250 sheets (8.5" x 11" or smaller),
50 sheets (8.5" x 14" or larger)
Shift Tray: 2,000 sheets (8.5" x 11" or
smaller), 1,000 sheets (8.5" x 14" or larger),
500 sheets (5.5" x 8.5")
Booklet Tray: 30 sets (2 – 5 sheets/set, all
sizes, saddle-stitch); 15 sets (6 – 10 sheets/
set, all sizes, saddle-stitch); 10 sets (11 – 15
sheets/set, all sizes, saddle-stitch)
Staple Capacity Normal Staple: 50 sheets (8.5" x 11" or
smaller), 30 sheets (8.5" x 14" or larger and/
or Mixed Sizes)
Saddle Stitch: 15 sheets (up to 60 pages)
Staple Paper Sizes Normal Staple: 8.5" x 11" – 11" x 17"
Saddle Stitch: 8.5" x 11", 8.5" x 14", 11" x 17",
A5 – A3
Staple Paper Weights 17 – 24 lb. Bond (64 – 90 g/m
2
)
Staple Positions 1 staple/3 positions (Top, Top Slant, Bottom);
2 staples/2 center positions
Staple Cartridge Normal Staple: 5,000 staples/cartridge
Capacity Saddle Stitch: 2,000 staples/cartridge
Dimensions (WxDxH)
25.9" x 24.1" x 37.8" (657 x 613 x 960 mm)
Weight 103.6 lb. (47 kg)
*Requires configuration with Bridge Unit (BU3060) and 550 x 2 Paper Feed Unit
(PB3130), 2,000-Sheet Large Capacity Tray (PB3140), or Large Cabinet Stand
(FAC 52)
4-Bin Mailbox Type CS3000* – Part # 407088
The 4-Bin Mailbox Type CS3000 can be installed by itself or simultaneously
with either Finisher; with or without paper supply options.
Number of Bins 4 bins
Capacity Per Bin 125 sheets x Trays = 500 sheets
Paper Size 5.5 x 8.5" – 11" x 17", A3, A4, A5, A6
Paper Weight 16 – 34 lb. Bond (60 – 128 g/m
2
)
Dimensions (WxDxH)
17.3" x 18.7" x 14.8" (440 x 475 x 375 mm)
Weight 17.6 lb. (8 kg)
Punch Unit Type PU3030 – Part # 430719
The Hole Punch Unit Type PU3030 is optional for both Finishers; installs
inside the Finisher.
Punch Paper Sizes 2 holes: 5.5" x 8.5" – 11" x 17", A5 – A3
3 holes: 8.5" x 11", 11" x 17", A4 – A3
Punch Paper Weight
14 – 43 lb. Bond / 90 lb. Index (52 – 163 g/m
2
)
Bridge Unit (BU3060) – Part # 415988
The Bridge Unit (BU3060) is a required accessory when the main unit is to
be configured with either Finisher. The Bridge Unit transports pages from
the printer’s standard exit area into a Finisher for online stapling, punching,
and/or folding.
Sheet Capacity 250 sheets (8.5" x 11" or smaller),
125 sheets (8.5" x 14" or larger)
Output Jogger Unit Type 9002A – Part # 415903
The Output Jogger Unit Type 9002A is optional for the 3,000-Sheet Finisher
only. It taps sheets in the Shift Tray into aligned sets for stacking or off-line
binding.
Paper Size 5.5" x 8.5" – 11" x 17", A5 – A3
Paper Weight
14 – 68 lb. Bond / 140 lb. Index (52 – 256 g/m
2
)
Shift Capacity Up to 20 mm
Dimensions (WxDxH) 4.25" x 17.8" x 5.1" (108 x 452 x 130 mm)
Weight 4.4 lb. (2 kg)
Supplies
Consumables Part # Yield*
Print Cartridge Black (Type SP C830DNA) 821117 23,500*
Print Cartridge Yellow (Type SP C830DNA) 821118 27,000*
Print Cartridge Magenta (Type SP C830DNA) 821119 27,000*
Print Cartridge Cyan (Type SP C830DNA) 821120 27,000*
Black Drum Unit (Type SP C830DN) 407095 60,000
Color Drum Unit (Type SP C830DN) 407096 60,000 x 3
(Includes Cyan, Magenta & Yellow units)
Transfer Unit (Type SP C830DN) 407097 200,000
Fusing Unit (Type SP C830DNA) 407098 160,000
Waste Toner Bottle (Type SP C830DN) 407100 40,000
Staple Type K for SR3120 Finisher 410801 5,000/carton
Staple Type K Refill for SR3120/SR3110 410802 15,000
Staple Type S for SR3110 (Saddle Stitch) 412874 5,000/carton
(Uses Type K refill)
*Declared yield values in accordance with ISO/IEC 19798.
For maximum performance and yield, we recommend using genuine Ricoh
parts and supplies.
Warranty
The Ricoh Aficio SP C830DN and SP C831DN is under warranty against
defects for a period of one year from the date of purchase. Consumables
are under warranty for a period of 90 days from the date of purchase or
until depleted, which ever comes first. Please refer to warranty documents
shipped with the product for more details.
www.ricoh-usa.com

Ricoh Aficio SP C830DN Specifications
