Using a Printer Server
264
7
N Click [Configuration], click [Parallel] in the [Printer type] list, and then click
[Communication].
O Click [Manual load] in the [Communication type] area, and then click [OK].
Check the settings, and then click [OK].
P Set up the network connection to a print server. Select a context specified
using NIB Setup Tool, and then click [Create] on the [Object] menu.
Q In the [Class of new object] box, click [Print Server], and then click [OK]. For
NetWare 5, click [Print Sever (Non NDPS)].
R In the [Print Server Name] box, enter the print server name.
Use the same print server name specified using NIB Setup Tool.
S Select the [Define additional properties] check box, and then click [Create].
T Assign the printer to the created print server. Click [Assignments], and then
click [Add] in the [Assignments] area.
U In the [Available objects] box, click the queue you created, and then click [OK].
V In the [Printers] area, click the printer you assigned, and then click [Printer
Number].
W Enter the printer number, and then click [OK]. Check the settings, and then
click [OK].
Use the same printer number specified as the remote printer number using
NIB Setup Tool.
X Start the print server by entering the following from the console of the Net-
Ware server.
If the print server is in operation, quit and restart it.
❖ To exit
CAREE: unload pserver
❖ To start
CAREE: load pserver “print_server_name”
Y Enter the printer server name as the context name, and then press the {OK} key.
Z Select the printer name on the context menu, and then press the {KO} key.
Setting up using Web Image Monitor
A Start Web Image Monitor.
B Click [Login].
A dialog box for entering the [Login User Name] and [Login Password] appears.
