Guide to the Printer
12
1
8. Ventilator
This hole helps to keep components in-
side the printer from overheating.
Important
❒ Do not block or obstruct the venti-
lator. A malfunction may occur
due to overheating.
9. Front Cover Release Button
Use this button to open the front cover.
10. Power Switch
Use this switch to turn the printer power
on and off.
11. Paper Tray (Tray 1)
Loads up to 500 sheets of plain paper (80
g/m
2
, 20 lb.) into this tray for printing.
See “Paper and Other Media Supported
by this Printer”, Maintenance Guide.
Note
❒ Paper Tray is displayed “Tray 1” on
the panel display.
12. Friction Pad
This is required to feed in paper one sheet
at a time. Clean the friction pad when
more than one sheet of paper is fed into
the printer. Also, replace the friction pad
when the message, “Replace Mainte-
nance Kit”, appears.
13. Paper Tray Cover
Attach it when pulling out the tray exten-
sion of the paper tray.
14. Power Port
Connect the power cable to this port and
the other end of the cable to the outlet.
15. Rear Cover
Remove to install the optional duplex
unit or to replace the fusing unit.
16. Ventilators
These holes help to keep components in-
side the printer from overheating.
Important
❒ Do not block or obstruct the venti-
lators. A malfunction may occur
due to overheating.
17. Controller Board
Slide it out to install some options. Attach
the interface cable, the network interface
cable or the 1394 interface cable to the
board.
