Ricoh Caplio R1V User Manual

29
Quick Guide
5
55
5 When the Subject is not Centered
(Shooting with Focus-lock)
When your subject is not in the center of your composition, compose
your photo after focusing. (Focus-lock)
Example: Taking a photograph of the castle in the background
with the camera focused on a person in front.
1. To turn the power on, slide the power switch to open the
lens cover.
For how to turn the power on, see P.21.
2. Turn the Mode Selector to 5
55
5.
3. Put the subject of your photo right
in the center of the LCD Monitor or
the Viewfinder and press the
shutter button half-way.
Shooting range Subject to be focused on
Final still image

Ricoh Caplio R1V Specifications

General

Megapixel	5 MP
Camera type	Compact camera
Sensor type	CCD
Image sensor size	1/2.5 \
Maximum image resolution	2560 x 1920 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920
Optical zoom	- x
Focal length range	4.6 - 22.2 mm
Lens structure (elements/groups)	9/7
Interface	USB 1.1, AV out
Digital SLR	No
Built-in flash	Yes
Camera shutter speed	1 - 1/2000 s
Focal length (35mm film equivalent)	28 - 135 mm
Normal focusing range	0.3 - ∞ m
Auto focusing (AF) modes	centre weighted auto focus, spot auto focus
Macro focusing range (tele)	0.13 - ∞ m
ISO sensitivity	Auto
Flash modes	Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.13 - 2.1 m
Flash range (wide)	0.2 - 2.7 m
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	320 x 240 pixels
Display diagonal	1.8 \
Display resolution (numeric)	110000 pixels
Product color	Gold
Battery type	DB-50
Battery life (CIPA standard)	490 shots
Compatible memory cards	mmc, sd
Scene modes	Documents, Night, Portrait, Sports, Landscape (scenery)
White balance	auto, daylight, Fluorescent, Tungsten

Weight and Dimensions

Depth	25 mm
Width	100.2 mm
Height	55 mm
Weight	150 g
