Playback Menu
Note -------------------------------------------------------------------------------------
• You can connect the AV cable to the Video In terminal on your video recorder
and record what you have shot to a video recorder.
• The camera supports the following video standards: NTSC and PAL. Where
possible, the camera is set to the standard used in your country or region before
shipment; before connecting the camera to a device that uses a different video
standard, choose the appropriate video mode (GP.114).
• The camera body can be connected to TVs that support HDMI using an HDMI
cable (optional). See the documentation provided with TVs for details.
• If connecting or disconnecting the HDMI cable in multi-frame views of the
playback mode, the display switches to single frame view. When the menu
is displayed, it will not switch to single-frame view even if connecting or
disconnecting the HDMI cable.
• When connecting the camera body to a TV using a HDMI cable, the operational
sounds turn off.
• The resolution for HDMI output is set to [AUTO]. If the video resolution actually
shown on the display is low, change the [HDMI Output] settings in the setup
menu (GP.114).
